With the necessary checks complete, production can now commence. Either
the auto operation or step operation mode must be used to operate the machine
and place parts on a panel. Rather than directly entering auto operation, it is
best to use the step operation mode to operate the machine one cycle at a time
for several cycles to check that parts are being placed correctly on the panel.
If there are no problems then enter auto operation at that time.
Step Operation
Procedure
1. Select [Production] at the [Main] screen.
2. Select [Step] from the [Production Mode] section.
3.
Press the START button.
Notes: 1. If the nozzle check display appears on the operation panel, replace the
nozzle following the procedure given in section 3-5 Nozzle
Replacement. Once this is done make the necessary preparations in
accordance with the procedure outlined in Nozzle set check given in
this section and then enter Step operation.
2. If the device check display appears on the operation panel, follow the
procedure in Parts Set Check in section 4-1 to make the necessary
preparations and then enter Step operation.
4.2 Starting Production
Chapter 4: Starting Production
Preliminary
4-5CP-842E/842ME Operator’s Guide
Automatic Operation
Procedure
1. Select [Production] at the [Main] screen.
2. Select [Automatic] from the [Production Mode] section.
3. Press the START button.
Notes: 1. If the nozzle check display appears on the operation panel, replace the
nozzle following the procedure given in section 3-5 Nozzle
Replacement. Once this is done make the necessary preparations in
accordance with the procedure outlined in Nozzle set check given in
this section and then enter Step operation.
2. If the device check display appears on the operation panel, follow the
procedure in Parts Set Check in section 4-1 to make the necessary
preparations and then enter Step operation.
Chapter 4: Starting Production
Preliminary
4-6 CP-842E/842ME Operator’s Guide
Chapter 5
Stopping the Machine
5.1 Stopping the Machine Temporarily
5.2 Resetting the Machine from the Cycle Stop Status
5.3 Stopping the Machine in an Emergency
5.4 Resetting the Machine from the Emergency Stop Status
