When using rubber blocks.
Snap the blocks into suitable lengths and use double-faced tape to stick them
to the backup plate.
Note: If there are pre-placed parts on the underside of a panel the installation
of back-up pins must take this into account so as to avoid a collision
with any of these parts.
Chapter 3: Preparing for Production
Preliminary
3-22 CP-842E/842ME Operator’s Guide
Chapter 4
Starting Production
4.1 Measurements and Checks Prior to Production
4.2 Starting Production
Preliminary
4-1CP-842E/842ME Operator’s Guide
Nozzle Bend and Nozzle Center Measurement
Carry out nozzle bend and nozzle center measurement on each nozzle before
actually entering production. These measurements are collectively referred to
as nozzle check. If nozzle check is not executed prior to production there is a
possibility that placement deviations will occur. Always perform nozzle check
prior to production.
Caution: When performing nozzle center measurement, a nozzle of at least 0.7
mm in diameter must be mounted at position 1 on all of the heads.
Procedure
1. Select [Nozzle Check] from the [Set Up] section in the [Main]
screen.
2. Select the items for which inspection is to be carried out from the
[Inspection Item] section.
Note: For black nozzles, only [Nozzle Length] inspection is to be carried out.
3. Select the nozzles for which nozzle check is to be carried out
from the [Holder] section.
Note: It is possible for multiple nozzles to be selected. Select [ALL] to select
all nozzles.
4. Select [Wide Camera] or [Narrow Camera] from the [Change
Camera] section in order to change the camera used to display
the status of the inspection results of each nozzle during mea-
surement.
5. Once the settings are complete, press [Start] in the [Holder] sec-
tion.
This will enable the the START button.
4.1 Measurements and Checks Prior to
Production
Chapter 4: Starting Production
Preliminary
4-2 CP-842E/842ME Operator’s Guide
