Chapter 3

Preparing for Production

3.1 Setting the Operation Mode

3.2 Production Programs

3.3 Device Tables

3.4 Parts

3.5 Machine

Preliminary

3-1CP-842E/842ME Operator’s Guide

Setting the Operation Mode

The machine operation mode must be set to "Production" in order to place

parts on a panel.

Production: This is the mode used for regular production.

Idle: The idle modes must only be used when there

are no parts loaded in the device slots

employed in the production program. The

idle modes are used for warning up the

machine and are not used for production.

Idle operation with loading: The loading and unloading of panels has been

added to the standard idle operation mode.

Operation must be performed without parts

being loaded to the device slot specified by

the program.

Idle operation without pickup: Operates in the same manner as the standard

idle mode except that pickup is not

performed.

Pass: Pass mode is used when the machine is not

used in current production. In pass mode the

machine simply acts as a conveyor, moving

the panel on to the next machine in the line.

Procedure

1. From the [Main] screen select [Operation] to display the

[Operation] screen.

2. Among three modes; [Prodution], [Idle], [Pass], set the operation

mode to [Production].

3. Press [Close] to return to the [Main] screen.

3.1 Setting the Operation Mode

Chapter 3: Preparing for Production

Preliminary

3-2 CP-842E/842ME Operator’s Guide

Preparing for Production Data Transmission

The operating status of the machine during production is saved in files referred

to as production logs. This production data is managed at the host computer.

Set the machine to the transmission mode so that the production data can be

sent to the host computer.

Procedure

1. Select [HOST] from the [Main] screen.

2. Select [ON] from the [Communication Status] section.

3. Select [Online] from the [Control Status] section.

4. Select [Remote].

5. Press [Close] to return to the [Main] screen.

Note: When the CP-842E/842ME starts up, the machine settings are as described

above. Usually it is not necessary to input these settings.

Chapter 3: Preparing for Production

Preliminary

3-3CP-842E/842ME Operator’s Guide
