Frequency Every 8 hours Procedure W ARNING Be sure to turn the 200V power off before performing this procedure. Use a vacuum cleaner to suck up any waste tape scattered around the waste tape suction path. 7.2 Cleaning th…
Frequency
Every 8 hours
Procedure
When emptying the waste tape box, also check the filter immediately above it.
If the filter is soiled, clean it with a vacuum cleaner.
Note: When cleaning is complete, ensure that the waste tape box and filter are
inserted all the way back to their original positions.
7.1 Cleaning the Waste Tape Box and Filter
Chapter 7: Maintenance
Preliminary
7-2 CP-842E/842ME Operator’s Guide
Frequency
Every 8 hours
Procedure
WARNING
Be sure to turn the 200V power off before performing this
procedure.
Use a vacuum cleaner to suck up any waste tape scattered around the waste
tape suction path.
7.2 Cleaning the Waste Tape Suction Path
Chapter 7: Maintenance
Preliminary
7-3CP-842E/842ME Operator’s Guide
Frequency
Every 8 hours
Procedure
WARNING
Be sure to turn the 200V power off before performing this
procedure.
Pull the lever forward then slide the reject parts box sideways and pull it out
as shown below.
7.3
Emptying the Reject Parts Box
Chapter 7: Maintenance
Preliminary
7-4 CP-842E/842ME Operator’s Guide
