It is possible to automatically stop the machine when all panels in the machine (in-conveyor , in-carrier, and XY -table) are produced and the last one is unloaded to the out-conveyor . Procedure 1. Press [Finish All Pan…
The machine stops automatically once the scheduled production quantity is
produced. Refer to, "Setting the Scheduled Production Quantity" in section
3-2 regarding the procedure for setting the scheduled production quantity.
Note: Once the scheduled production quantity for a production program has
been completed, clear the production quantity counter to use the produc-
tion program again. Refer to "Clearing the Production Quantity Count"
in section 8-14 regarding this procedure.
During the course of production it is possible to automatically stop the
machine once the panel(s) currently on the XY-table is completed and
unloaded to the out-conveyor.
Procedure
1. Press [Finish Current Panels] while production on the machine
is in progress.
2. Once production of the panel(s) currently being produced (panel
on the XY-table) is finished and the panel is unloaded to the out-
conveyor, the machine will automatically stop.
Note: If a panel is not unloaded to the next machine and the panel is left on the
out-conveyor, panels on the out-carrier and XY-table cannot be unloaded.
Remove the panels on the out-conveyor in order.
6.2 Stopping Automatically After Current
Panel is Completed
6.1 Stopping Automatically Upon Completion
of the Scheduled Production Quantity
Chapter 6: Finishing Production
Preliminary
6-2 CP-842E/842ME Operator’s Guide
It is possible to automatically stop the machine when all panels in the machine
(in-conveyor, in-carrier, and XY-table) are produced and the last one is
unloaded to the out-conveyor.
Procedure
1. Press [Finish All Panels] while production is in progress on the
machine.
2. The machine will automatically stop after all panels on the in-
conveyor, in-carrier, and XY-table have been produced and
unlaoded.
Note: If a panel is not unloaded to the next machine and the panel is left on the
out-conveyor, panels on the out-carrier and XY-table cannot be unloaded.
Remove the panels on the out-conveyor in order.
6.3 Stopping Production Automatically After
All Panels Remaining in the Machine are
Completed
Chapter 6: Finishing Production
Preliminary
6-3CP-842E/842ME Operator’s Guide
Notes
Chapter 6: Finishing Production
Preliminary
6-4 CP-842E/842ME Operator’s Guide
