Windows XP Unattended Setup DVD V4.2 11/2015 Edition
7
3 Requirements
3.1 Hardware
Minimum Hard Disk Capacity:
25 GB
Minimum System Memory:
512 MB RAM
Supported Computer Hardware in this (DVD-) version:
ECONEL 30
with Board D1447
SIPLACE Pro
ECONEL 40
with Board D1755
SIPLACE Pro
ECONEL 50
with Board D1859
SIPLACE Pro
ECONEL 100
with Board D2179
SIPLACE Pro
ECONEL 100 (Dual Core)
with Board D2179
SIPLACE Pro
Celsius W360
with Board D2587
SIPLACE Pro
Celsius W370 E80+/E85+
with Board D2817-A1
SIPLACE Pro
SIMATIC Box PC 627
with Board a5e00329102
SIPLACE HS-D / X-Series
SIMATIC Box PC 627B
SIPLACE HS-D / X-Series / SX
SIMATIC Box PC 827B
SIPLACE HS-D / X-Series / SX
ESPRIMO E 5700
with Board D2334
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5
ESPRIMO P 5700
with Board D2331
SIPLACE HS-60 / HS 50/ 50+
ESPRIMO C 5910
with Board D2364
SIPLACE Compact
ESPRIMO E 5915
with Board D2344
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5
ESPRIMO P 5915
with Board D2312
SIPLACE HS-60 / HS 50/ 50+
ESPRIMO E 5925
with Board D2598
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5
ESPRIMO E 7935 E85+
with Board D2828-A2
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5
ESPRIMO E 7936
with Board D3028-A1
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5
ESPRIMO E 900
with Board D3062-A1
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5 /
HS-60 / HS 50/ 50+ / Compact
Kontron KTQ45
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5 /
HS-60 / HS 50/ 50+ / Compact
Kontron KTQ67
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5 /
HS-60 / HS 50/ 50+ / Compact
Windows XP Unattended Setup DVD V4.2 11/2015 Edition
8
Supported Touch Screen Displays:
Elo Touch (15”)
Micro Touch (15”)
PenMount Touchscreen (15”)
Not Supported Computer Hardware, Support Only In CD Version V 2.08 / V 3.0:
SCENIC C 600
with Board D1544
SIPLACE Compact
SCENIC C 610
with Board D1644
SIPLACE Compact
SCENIC N 300
with Board D1561
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5
SCENIC N 320
with Board D1521/D1561/D1961
SIPLACE F5 HM / S-20 / S-23 / S-25HM / S-27HM / F4 / F5
SCENIC P 300
with Board D1561
SIPLACE HS-60 / HS 50/ 50+
SCENIC P 320
with Board D1521/D1561/D1961
SIPLACE HS-60 / HS 50/ 50+
CPU 076
SIPLACE HF-Series
CPU 086
SIPLACE X-Series
3.2 Required configuration parameters
For the installation procedure, please note the following information:
3.2.1 Common settings
1
User Name
2
Company Name
3
License Key of the Operating System
4
Custom hard disk partition sizes, if required
Note:
We recommend gluing the Operating System License Key on the case of the computer to avoid
loss.
3.2.2 Station Computer settings
5
IP configuration of each network adapter, especially the connection(s) to the machine controller and
the line computer.
- IP address
Windows XP Unattended Setup DVD V4.2 11/2015 Edition
9
- Subnet mask
- Default gateway (Optional, if no Remote Support was installed no entry.
Default: no entry)
6
Custom Hosts- File entries as required - especially machine controller and line computer entries.
7
Used touch screen type
3.2.3 Vision Computer settings
5
IP configuration of each network adapter, especially the connection(s) to the stations.
- IP address
- Subnet mask
- Default gateway (Optional, if no Remote Support was installed no entry.
Default: no entry)
6
Custom Hosts- File entries, if required
3.2.4 Line Computer settings
5
IP configuration of each network adapter, especially the connection(s) to the stations and other
SIPLACE computers.
- IP address
- Subnet mask
- Default gateway (Optional, if no Remote Support was installed no entry.
Default: no entry)
6
Custom Hosts- File entries, if required
