6.7 List of P783 Jumper Settings SERVICE MANUAL A VK3 6.7−7 D77SEC−85−040−A0 SC JA-M00016-A1 12345678 ON OFF SW3 12345678 ON OFF SW2 1234 ON OFF SW1 P N M L K J H F E D C B A DIP SW 1 Details Meaning SW No. Function OFF …
6.7 List of P783 Jumper Settings
SERVICE MANUAL
AVK3
6.7−6
D77SEC−85−040−A0
MMI LA-M00105-3F 4/4
Jumper explanation
JP
Functions ON setting OFF setting
Set-
tings
JP39
+12V supply to RS232C
CN1-B-14pin
ON
Supplies power
OFF
No power supply
OFF
JP40
−12V supply to RS232C
CN1-B-16pin
ON
Supplies power
OFF
No power supply
OFF
JP41 Multi bus high enable
1-2
Effective
1-3
Ineffective
1-3
JP42
Address changeover
(1M, 2M and 4M)
1-2
1M, 2M
1-3
4M
1-3
JP43
Reset signal timing change-
over ordinary/Intel ICE used
1-2
Ordinary
1-3
Intel ICE used
1−2
JP44 1-2 short fixed
1-2
If 1-2 short circuited
ordinary
1-3
If 1-3 short circuited
1−2
LED monitor
Name
Explanation Remark
LED1 Error of watchdog timer time over (Light OFF)
LED2 Error of LP1 (Light OFF)
LED3 Error of LP1 Broken wire (Light OFF)
LED4 LP1 communication error (Light OFF)
LED5 Error of LP2 (Light OFF)
LED6 Error of LP2 Broken wire (Light OFF)
LED7 LP2 communication error (Light OFF)
6.7 List of P783 Jumper Settings
SERVICE MANUAL
AVK3
6.7−7
D77SEC−85−040−A0
SC JA-M00016-A1
12345678
ON
OFF
SW3
12345678
ON
OFF
SW2
1234
ON
OFF
SW1
P
N
M
L
K
J
H
F
E
D
C
B
A
DIP SW 1 Details Meaning
SW No.
Function OFF ON Default
1 Selection of Compiler RAM ROM ON
SW No.
Function
Default
2 3 4
F
unc
ti
on
D
e
f
au
lt
OFF OFF OFF Standard (All 10 ms mode) OFF
ON OFF OFF Hard timer 1 ms mode OFF
OFF ON OFF Not use OFF
ON ON OFF Not use OFF
OFF OFF ON Not use OFF
ON OFF ON Not use OFF
OFF ON ON Not use OFF
ON ON ON Not use OFF
6.7 List of P783 Jumper Settings
SERVICE MANUAL
AVK3
6.7−8
D77SEC−85−040−A0
DIP SW 2 Details
Meaning
SW No.
Function OFF ON Default
1 Movement mode selection Normal System
2 Selection of auto width spec. Invalid Valid
3 Selection of connection signal unloader slide PBS
Unloader
connect.
sig.
4 P.C.B. flow selection
Right to
left
Left to
right
5 Right positioning spec. Invalid Valid
6
Sl ti
f
t
ifi ti
/
Sl ti
Rf
t
th
di
7
Selection o
f
customer specification
/
Selection
of
copiler
Refer to the diagram
No.
3
8
of
copiler
No
.
3
Diagram 3
SW No.
Function
Default
6 7 8
F
unc
ti
on
D
e
f
au
lt
ON OFF OFF
Select of connection signal loader side
(Connection of single)
OFF ON OFF
Select of connection signal loader side
(BSF−V unit standard spec.)
ON ON OFF
Select of connection signal loader side
(BSF−V unit with 1 P.C.B. wait spec.)
OFF OFF ON
Select of connection signal loader side
(BSF−V unit with safety cover spec.)
DIP SW 3 Details Meaning
SW No.
Function OFF ON Default
1 Optical loop 1 error interruption Not enable Enable OFF
2 Optical loop 2 error interruption Not enable Enable OFF
3 Optical loop 3 error interruption Not enable Enable OFF
4 Optical loop 4 error interruption Not enable Enable OFF
5 Wire sub−control error interruption Not enable Enable OFF
6 Not use OFF
7 Not use OFF
8 EP−ROM capacity sekection 256k Bit 1M Bit OFF
