6 . 8 Secret Screen Service Functions (CONFIDENTIAL) SERVICE MANUAL A VK3 6.8−1 D77SEC−85−080−A0 6 . 8 Secret Screen Service Functions (CONFIDENTIAL) D77SEC−85−080−A0 Sentence No. =NOTE= Secret screen service functions a…
6.7 List of P783 Jumper Settings
SERVICE MANUAL
AVK3
6.7−12
D77SEC−85−040−A0
RC FA-M00861-43 3/3
Dip switch setting
No. Contents
Standard
setting
Specification
1 ON ADR 19
2 OFF ADR 18
3 OFF ADR 17
4
2
ports
RAM
upper
address
seen
from
main
ON ADR 16
5
2
por
t
s
RAM
upper a
dd
ress seen
f
rom ma
i
n
OFF ADR 15
6 OFF ADR 14
7 OFF ADR 13
8 OFF ADR 12
FA−86110C−2 switch setting
SW
No.
Explanation
Standard
setting
Specification
SW
A/D clock select
INT : Internal clock
EXT : External clock (MAX 20MHz)
EXT
1
INT
EXT
SW1
EXT
SW
A/D conversion reference changeover
1 : 0 Vpp − 1.0 Vpp
2 : 0 Vpp − 0.7 Vpp
1
SW
2
1
2
SW2
1
ON
SW
ON
1 2 3 4 5 f’ Camera
SW
3
OFF ON OFF OFF OFF 12.1151 −−−−−
3
1
5
SW3
OFF OFF OFF ON OFF 12.2095 GP−MF102
5
SW3
6.8 Secret Screen Service Functions (CONFIDENTIAL)
SERVICE MANUAL
AVK3
6.8−1
D77SEC−85−080−A0
6.8 Secret Screen Service Functions (CONFIDENTIAL)
D77SEC−85−080−A0
Sentence No.
=NOTE=
Secret screen service functions are avaiable only at SYTEM MANAGER LEVEL of
operating levels.
6.8.1 How to Enter to the Secret Screen
1. Turn the power [ON].
2. Select “MANU” → ”REQUEST” → “F7” (OPERATION LEVEL SETTINGS) on the main
control panel.
3. Input pasword to change the current operating level to SYSTEM MANAGER LEVEL.
=NOTE=
As the password of SYSTEM MANAGER LEVEL is changeable, ask customer for it.
The default password of SYSTEM MANAGER LEVEL is ’PASS2’
6.8 Secret Screen Service Functions (CONFIDENTIAL)
SERVICE MANUAL
AVK3
6.8−2
D77SEC−85−080−A0
6.8.2 RAM All Clear
1. Select “MANU” → ”REQUEST” → “F8” → “F1” (MACHINE INITIALIZE VALUE SETTING) →
“F3” (PRUODUCTION CONDITIONS SETTING) → “F2” (CLEAR MEMORY) → “F7” → “A”
→ “F7” → “J” → “F7” → “F1” (RAM ALL CLEAR) on the main control panel.
<F1> <F2> <F3> <F4> <F5> <F6> <F7> <F8>
YYYY − MM − DD HH : MM
THIS IS TO CLEAR ALL RAM AREA DATA.
MANUAL : 1 BLOCK << M/C INI. VAL. SET >>
RETURN
TO DISP
CLEAR ALL RAM AREA DATA.
RAM ALL CLEAR
INITIALIZATION ATTEMPT? ( F1 : YES F2 : NO )
YES NO
Figure 6.8−1:RAM All Clear
Description of parameters
• This is a designation of whether all RAM area will be initialized or not.
F1 : All RAM area will be initialized.
F2 : All RAM area will not be initialized.
