1.1 Use of This Manual
SERVICE MANUAL
AVK3
1.1−1
D77SEC−06−020−A0
1.1 Use of This Manual
D77SEC−06−020−A0
Sentence No.
1.1.1 Concerning Secrecy
• This manual contains information which, if leaked to outside parties, might cause harm to
MED business and/or seriously affect safety conditions. For that reason, we would ask you
strictly not to distribute any information of this manual to customers.
• We would like to ask you, Panasert sales and/or service offices, to administer the secret infor-
mation thoroughly.
1.1.2 Use of This Manual
• This manual is prepared only for service engineers who are in charge of MED products at
service offices.
• This manual is based on standard machine specifications. Style, type number , module number ,
etc. of EC and the specific bloc may be dif ferent from standard machine. Therefore it is recom-
mended to refer to its operating instructions, parts list, wiring diagram of control system.
• More technical informations and service hints will be added when necessary.
• Illustration of this manual, etc., might differ from the actual machine shape because of specifi-
cation changes.
1.1.3 Sentence Numbers
• Sentence number is assigned to each section for document management.
Explanation of sentence number
’Section control number’
’Document’
’D’ indicates that this number is not sheet number.
’Revisions history’ for specification change
’Manual type’
M : Service manual
’Machine type’
’Language’
J : Japanese, E : English
’Regulations’
C : for all countries, E : for EC, P : for Japan and all countries
except EC
’Chapter control number’
’Revisions history’ for sentence or spelling mistake
’Revisions history’
This part will be changed for revisions.
Ex.
