5.1 AC Servo Gain Adjustment
SERVICE MANUAL
AVK3
5.1−5
D77SEC−84−040−A0
10. Driver settings will be done on screen as follows
X Axis Move Gain
distance
high
speed
accelerate
posi prorl
speed
prorl
speed
integra
feed forward
POST1 0 ∼ 6667 270 13 7 0 5
POST2 2.51 ∼ 6667 620 13 7 0 5
POST3 5.51 ∼ 6667 850 13 7 0 5
POST4 7.41 ∼ 6667 1000 13 7 0 5
POST5 8.61 ∼ 6667 1100 13 7 0 5
POST6 9.71 ∼ 6667 1200 13 7 0 5
POST7 10.51 ∼ 6667 1400 13 7 0 5
POST8 12.01 ∼ 6667 1550 13 7 0 5
POST9 13.51 ∼ 6667 1600 13 7 0 5
POST10 14.21 ∼ 6667 1700 13 7 0 5
ORIGIN − 750 500 5 3 1 0
TCH(L) − 38 25 8 3 2 0
TCH(H) − 250 100 8 3 2 0
X Axis Stop Gain
posi prorl speed prorl speed integra change time
POST1 10 6 3 0
POST2 10 6 3 0
POST3 10 6 3 0
POST4 10 6 3 0
POST5 10 6 3 0
POST6 10 6 3 0
POST7 10 6 3 0
POST8 10 6 3 0
POST9 10 6 3 0
POST10 10 6 3 0
ORIGIN 6 3 1 0
TCH(L) 10 6 3 0
TCH(H) 10 6 3 0
5.1 AC Servo Gain Adjustment
SERVICE MANUAL
AVK3
5.1−6
D77SEC−84−040−A0
X Axis 2 Move Gain
distance
high
speed
accelerate
posi prorl
speed
prorl
speed
integra
speed
forward
POST1 0 ∼ 6667 1800 13 7 0 5
POST2 16.11 ∼ 6667 1900 13 7 0 5
POST3 17.01 ∼ 6667 2100 13 7 0 5
POST4 18.51 ∼ 6667 2300 13 7 0 5
POST5 19.51 ∼ 6667 2400 13 7 0 5
POST6 20.81 ∼ 6667 2450 13 7 0 5
POST7 21.61 ∼ 6667 2600 13 7 0 5
POST8 23.01 ∼ 6667 2700 13 7 0 5
POST9 24.01 ∼ 6667 2800 13 7 0 5
POST10 0 ∼ 0 0 0 0 0 0
ORIGIN − 0 0 0 0 0 0
TCH(L) − 0 0 0 0 0 0
TCH(H) − 0 0 0 0 0 0
X Axis 2 Stop Gain
posi prorl speed prorl speed integra change time
POST1 10 6 3 0
POST2 10 6 3 0
POST3 10 6 3 0
POST4 10 6 3 0
POST5 10 6 3 0
POST6 10 6 3 0
POST7 10 6 3 0
POST8 10 6 3 0
POST9 10 6 3 0
POST10 10 6 3 0
ORIGIN 0 0 0 0
TCH(L) 0 0 0 0
TCH(H) 0 0 0 0
5.1 AC Servo Gain Adjustment
SERVICE MANUAL
AVK3
5.1−7
D77SEC−84−040−A0
Y Axix Move Gain
distance
high
speed
accelerate
posi prorl
speed
prorl
speed
integra
feed forward
POST1 0 ∼ 6667 270 18 8 0 9
POST2 2.51 ∼ 6667 430 18 8 0 9
POST3 3.71 ∼ 6667 620 18 8 0 9
POST4 5.71 ∼ 6667 830 18 8 0 9
POST5 6.91 ∼ 6667 1470 18 8 0 9
POST6 11.61 ∼ 6667 2050 18 8 0 9
POST7 17.01 ∼ 6667 2250 18 8 0 9
POST8 19.01 ∼ 6667 2600 18 8 0 9
POST9 22.01 ∼ 6667 2850 18 8 0 9
POST10 25.01 ∼ 6667 3030 18 8 0 9
ORIGIN − 750 500 8 3 3 0
TCH(L) − 38 25 10 3 3 1
TCH(H) − 250 100 10 3 3 1
Y Axix Stop Gain
posi prorl speed prorl speed integra change time
POST1 15 12 1 10
POST2 15 12 1 10
POST3 15 12 1 10
POST4 15 12 1 10
POST5 15 12 1 10
POST6 15 12 1 10
POST7 15 12 1 10
POST8 15 12 1 10
POST9 15 12 1 10
POST10 15 12 1 10
ORIGIN 8 5 1 0
TCH(L) 12 5 1 0
TCH(H) 12 5 1 0
