6.5 Dip Switch Contents List SERVICE MANUAL A VK3 6.5−4 D77SEC− 85− 020− A0
6.5 Dip Switch Contents List
SERVICE MANUAL
AVK3
6.5−3
D77SEC−85− 020−A0
(3) SC
DSW No.
Contents OFF setting ON setting
Standard
setting
1 Compile select ROM RAM OFF
2 Auto width control Invalid Valid OFF
3
Option 1
(rear connection)
PBS Others OFF
4 PCB transfer direction R → L L → R OFF
5 PCB reference posion Left reference Right reference OFF
6
Oti
2
OFF
7
Option 2
(front
connection)
Refer to the following detailed explanation.
OFF
8
(front
connection)
g
p
OFF
Detailed explanation
DSW No.
Contents
6 7 8
C
on
t
en
t
s
OFF OFF OFF −
OFF OFF ON BSF−V ( safety stop )
OFF ON OFF BSF−V
OFF ON ON −
ON OFF OFF Loader connection signal
ON OFF ON −
ON ON OFF BSF−V ( 1 PCB standby )
ON ON ON −
6.5 Dip Switch Contents List
SERVICE MANUAL
AVK3
6.5−4
D77SEC−85− 020−A0
6.6 SC Timer Table
SERVICE MANUAL
AVK3
6.6−1
D77SEC−85−030−A0
6.6 SC Timer Table
D77SEC−85−030−A0
Sentence No.
TM
Standard
setting
(SEC)
Functions
TM1 1.80 L. STOP check
TM2 0.05 Carry miss check
TM3 0.50 H axis brake release action
TM4 1.00 Dust collection action
TM5 0.50 Warning lamp blink 1
TM6 0.50 Warning lamp blink 2
TM7 0.50 Loader belt motor action
TM8 0.10 PCB transfer traverse action
TM9 0.10 Loader / unloader action
TM10 5.00 Loader rail down action
TM11 5.00 Loader rail up action
TM12 5.00 Unloader rail down action
TM13 5.00 Unloader rail up action
TM14 5.00 Positioner lever down action
TM15 5.00 Positioner lever up action
TM16 0.20 Chuck slide stop action
TM17 5.00 PCB Transfer traverse action
TM18 5.00 PCB Transfer return action
TM19 10.00 Loader rail load action
TM20 10.00 Unloader rail load action
TM21 15.00 PCB wait
TM22 5.00 P. PULL traverse action
TM23 5.00 P. PULL return action
TM24 5.00 P. PUSH traverse action
TM25 5.00 P. PUSH return action
TM26 0.50 ZR parts change demand
TM27 5.00 Chuck slide traverse action
TM28 5.00 Chuck slide return action
TM29 5.00 JW set traverse action
