MULTI INTERFACE UNIT Selecting this diagnostics module opens the following window: The menu bar changes to the following: Toggle Next Previous Exit Next / Previous keys move the highlight bar up and down the list of sele…
Table at Home This diagnostic function continuously displays the status of the home interlock
sensor. On is displayed when the rising table is in the home position.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
5.30 User Manual Software Version 6
DIAGNOSTICS
RISING TABLE
MULTI INTERFACE UNIT
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Toggle Next Previous Exit
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Toggle activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
NOTE
This diagnostic can only be run when the machine is connected to an upline and
downline machine.
Toggle Available A This diagnostic function is currently not used.
Toggle Upline A Selecting this diagnostic function sends a request to the upline machine to send a
board.
Toggle Downline A Selecting this diagnostic function sends a request to the downline machine to
receive a board.
Machine Available AThis diagnostic function is currently not used.
Downline Ready A This diagnostic function continuously displays whether the downline machine is
ready to receive a board.
Upline Ready A This diagnostic function continuously displays whether the upline machine is
ready to send a board.
Software Version 6 User Manual 5.31
DIAGNOSTICS
MULTI INTERFACE UNIT
MIU D
i
agnost
i
cs
CLEAR
SET
CLEAR
OFF
ON
OFF
Machine Available A
Downline Ready A
Upline Ready A
Toggle
Available A
Upline A
Downline A
AUTOFLEX TOOLING
Selecting this diagnostics module opens the following window:
The menu bar changes displaying the following:
Run
Diagnost
Next Previous Exit
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Tooling Pins Selecting this diagnostic function alternately lifts and lowers all the pins,
continuously displaying the current status.
Clamp Enable Selecting this diagnostic function alternately switches the electromagnet clamps
on or off, continuously displaying the current status. Any pins that are up when
the clamp is switched off automatically lower.
Clamp Power Selecting this diagnostic function alternately switches the power through the
electromagnetic coils between high and low, continuously displaying the current
status.
5.32 User Manual Software Version 6
DIAGNOSTICS
AUTOFLEX TOOLING
Autof
l
ex D
i
agnost
i
cs
ON
Down
LO
Tooling Pins
Clamp Enable
Clamp Power
Change Pin Status
Cycle Autoflex Tooling
