EVENT DISPLAY Displays the machine event record in a tabular format. To view the event record
proceed as follows:
1. Select Event Display.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The Event Record window is displayed as follows:
2. Select Latest to access latest machine events.
Select Next to access later machine events.
Select Previous to access earlier machine events.
Latest Next Previous
Exit
3. Select Exit.
Latest Next Previous
Exit
Software Version 6 User Manual 6.7
MONITOR
EVENT DISPLAY
Date
05/09/97
05/09/97
05/09/97
05/09/97
05/09/97
05/09/97
05/09/97
Time
11:08:58
11:11:02
11:11:37
11:13:31
11:13:52
11:14:36
11:16:12
11:16:45
11:17:01
11:17:59
31252
31251
31259
31269
31255
31273
31275
31279
31281
31289
05/09/97
05/09/97
05/09/97
Line Power Off
Line Power On
Paste Cartridge empty
Screen Loaded
Printer Ready
Clear Batch Count
Cover Closed
Setup Ended
System Power On
Clear Batch Count
Event
Event Record
SYSTEM DISABLE
To disable the system software proceed as follows:
1. Select System Disable.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The System Error window is displayed as follows:
2. Press the System button to re-initiate the system.
6.8 User Manual Software Version 6
MONITOR
SYSTEM DISABLE
System Error
System Power Down
CHAPTER 7
HOUSE KEEPING
