Change Pin Status Selecting this diagnostic function enables different pin patterns to be exercised. On selection the following window opens: The menu bar changes to the following: Lower Raise Set Status Left Right Up Do…
AUTOFLEX TOOLING
Selecting this diagnostics module opens the following window:
The menu bar changes displaying the following:
Run
Diagnost
Next Previous Exit
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Tooling Pins Selecting this diagnostic function alternately lifts and lowers all the pins,
continuously displaying the current status.
Clamp Enable Selecting this diagnostic function alternately switches the electromagnet clamps
on or off, continuously displaying the current status. Any pins that are up when
the clamp is switched off automatically lower.
Clamp Power Selecting this diagnostic function alternately switches the power through the
electromagnetic coils between high and low, continuously displaying the current
status.
5.32 User Manual Software Version 6
DIAGNOSTICS
AUTOFLEX TOOLING
Autof
l
ex D
i
agnost
i
cs
ON
Down
LO
Tooling Pins
Clamp Enable
Clamp Power
Change Pin Status
Cycle Autoflex Tooling
Change Pin Status Selecting this diagnostic function enables different pin patterns to be exercised.
On selection the following window opens:
The menu bar changes to the following:
Lower Raise Set
Status
Left Right Up Down Exit
Left, Right, Up and Down keys move the cursor to enable individual pins to be
selected.
Lower or Raise keys enable the selected pin to be raised or lowered.
Set Status key enables the AutoFlex to set the selected pin pattern. The message
Setting Up AutoFlex Tooling is displayed in the message window.
Exit returns operation to the AutoFlex diagnostics page.
Cycle AutoFlex
Tooling
Selecting this diagnostic function cycles the AutoFlex pins in a set pattern. The
pattern is as follows:
1. All the pins are raised.
2. The pins are lowered leaving a third raised, every third pin.
3. All the pins are raised.
4. The pins are lowered leaving a second third raised.
5. All the pins are raised.
6. The pins are lowered leaving the last third raised.
7. The process repeats until the Stop key is pressed.
Software Version 6 User Manual 5.33
