2 Brief description 2.1 Restrictions Assembly Instructions / Montageanleitung SIPLACE BulkFeeder X Retrofit Kit for SX Series and X Series S 07/2017 89 2 Brief description A machine-specific retrofit kit is required for …

1 Introduction

1.4 Staff Qualifications and Training

88 Assembly Instructions / Montageanleitung SIPLACE BulkFeeder X Retrofit Kit for SX Series and X Series S 07/2017

1.3.3.5 Dispatching ESD Modules

► Always store modules and components in conductive packaging (e.g. metalized plastic bags

or metal sleeves) and dispatch them in conductive packaging.

► If the packaging is not conductive, place the modules in a conductive envelope before pack-

aging. Use conductive expanded rubber, ESD bags, domestic aluminum foil or paper, for ex-

ample.

► If the module has integral batteries, ensure that the conductive packaging does not touch or

short-circuit the battery terminals and, if necessary, first cover the terminals with insulating

tape or material.

1.3.4 Release History

Document

SIPLACE SX series

SIPLACE X-Series S

Assembly Instructions

Edition Changes

07/2017 First edition

Assembly instructions for retrofitting an SIPLACE SX-Series or SIPLACE X-

Series S for operation with a BulkFeeder X.

1.4 Staff Qualifications and Training

Qualified or adequately trained personnel means that these people are familiar with the setting up,

operation and maintenance of the machine and the add-on devices and are suitably qualified, e.g.:

●

Have been trained, instructed or authorized to switch on and off, isolate, earth and identify

electrical circuits and system components in accordance with normal safety standards.

●

Have been trained or instructed in the upkeep and use of appropriate safety equipment in

accordance with normal safety standards.

●

Have received first aid training.

2 Brief description

2.1 Restrictions

Assembly Instructions / Montageanleitung SIPLACE BulkFeeder X Retrofit Kit for SX Series and X Series S 07/2017 89

2 Brief description

A machine-specific retrofit kit is required for putting BulkFeeder X devices into operation.

These retrofit kits can be ordered by quoting the following material numbers:

●

Retrofit kit BulkFeeder X for the SX-Series machine [00141660-xx]

●

Retrofit kit BulkFeeder X for the X-Series S machine [00141650-xx]

2.1 Restrictions

Restrictions for operating the BulkFeeder X are described in the BulkFeeder X user manual

[00198045-xx].

SX-Series

A maximum of two BulkFeeder X devices can be connected to the machine. This equates to one

BulkFeeder X per location.

X-Series S

A maximum of four BulkFeeder X devices can be connected to the machine. This equates to one

BulkFeeder X per location.

2.2 Tools and equipment required

The following tools and equipment are required for the work described in this manual:

●

Standard tools

●

Cable ties

●

Allen key, size 4, chrome-plated [03160943-xx]

Documents

Quant-

ity

Designation Item no.

1 BulkFeeder X - operating manual 00198045-xx

1 Retrofit kit for SX-Series and X-Series S - assembly instruc-

tions

00198243-xx

2 Brief description

2.3 Scope of delivery

90 Assembly Instructions / Montageanleitung SIPLACE BulkFeeder X Retrofit Kit for SX Series and X Series S 07/2017

2.3 Scope of delivery

2.3.1 Retrofit kit for SX-Series

The retrofit kit for the BulkFeeder [00141660-xx] contains:

Quant-

ity

Designation Item no.

1 Retrofit kit BulkFeeder El SX12 03147560-xx

1 Control computer Box PC IPC427D/i7 2xPCIe 03132220-xx

1 GigE ethernet adapter PCI-E I350T4V2BLK 03135985-xx

1 LAN Card PCI Gigabit SEMPRE NC1000-1 03112190-xx

1 Cable kit for retrofit kit BulkFeeder-X SX2: 03147561-xx

1 Adapter cable for power Box PC_BF 03147558-xx

1 Cable: LAN control computer BulkFeeder-X 03147557-xx

1 Cable: GigE BulkFeeder X feeder 4 3m 03147556-xx

1 Cable: GigE BulkFeeder X feeder 3 3m 03147555-xx

1 Cable: GigE BulkFeeder X feeder 2 03112557-xx

1 Cable: GigE BulkFeeder X feeder 1 03112556-xx

1 Cable: extension USB PC 03136110-xx

1 Cable: monitor 2 - video 03112239-xx

1 Cable: LAN hub control computer BulkFeeder X 03146380-xx

6 Cable ties W=4.8mm L=186mm TYB-25M 00805142- xx

4 Cable holder, self-adhesive, transparent 2x8mm 03148119-xx

1 Network switch RJ45 3 port 100Mbit/s 03145994-xx

1 Retrofit kit BulkFeeder mech. SX 03148110-xx

1 Mounting plate Box PC assy. 03148108-xx

1 Mounting rail B35xH7.5xL215, machined 03121132-xx

1 Carrier rail 215 mm 03058565- xx

2 ISO 7380-2 M 5 x 6-A2-70 03147951-xx

4 ISO 7380-2 M 4 x 8-A2-70 03099578-xx
