Samsung Component Placer CP-45F(V)/FS Operations Manual
B-10
- Then click on the NEXT button.
Step7 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step8 - Click on START or CONTINUE on MMI
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step9 - Press the START button to resume operation.
Error Code $0003 Link
Step Message
E - The rear emergency switch is pressed.
Step1 - Press the STOP button. (Stop the buzzer sound).
Step2 - Open the equipment door.
Step3 - Solve the problem that caused you to press the emergency switch.
- Then click on the NEXT button.
Step4 - Close the equipment door.
Step5 1. Cancel the emergency switch by turning it.
2. Press the RESET button.
- Then click on the NEXT button.
Step6 1. Turn on the power for motor.
2. Press the READY button.
- Then click on the NEXT button.
Step7 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step8 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step9 - Press the START button to resume operation.
Error Code $0004 Link
Step Message
E - The MOTOR FREE switch in the teaching box is pressed.
Step1 - Press the STOP button. (Stop the buzzer sound).
Step2 - Open the equipment door.
Step3 - Solve the problem that caused you to press the emergency switch.
- Then click on the NEXT button.
Step4 - Close the equipment door.
Step5 1. Press the RESET button.
- Then click on the NEXT button.
Step6 1. Turn on the power for motor.
2. Press the READY button.
- Then click on the NEXT button.
Step7 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Appendix B 3D Trouble Shooting Guide
B-11
Step8 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step9 - Press the START button to resume operation.
Error Code $0006 Link
Step Message
E - I/O power switch is off.
Step1 1. Press the STOP button. (Stop the buzzer sound).
2. Press the RESET button.
3. Turn on the power for MOTOR.
4. Press the READY button
- Then click on the NEXT button
Step2 1. Select the HOME mode by using the MODE button in the teaching box.
2.Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step3 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step4 - Press the START button to resume operation.
Error Code $0010 Link
Step Message
E - Front feeder unlock sensor is sensed.
Step1 1. Press the STOP button. (Stop the buzzer sound).
Step2 - Open the equipment door.
Step3 - Check if there are any loose feeders on the front feeder lane.
. Yes, there are loose feeders Step4
. No, there is no loose feeder. Step11
- Then click on the NEXT button.
Step4 - Secure the feeders completely.
- Then click on the NEXT button.
Step5 - Close the equipment door.
Step6 1. Press the RESET button.
2. Turn on the power for MOTOR.
3. Press the READY button.
- Then click on the NEXT button.
Step7 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then press the NEXT button.
Step8 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step9 - Press the START button to resume operation.
Step11 - Check the following.
… Check the connecting condition of the sensor and the reception and
dispatch positions.
… Check if there is any contaminant, such as vinyl or components, on
Samsung Component Placer CP-45F(V)/FS Operations Manual
B-12
the feeder.
… In the case of vibratory feeder, check if components are stacked up.
Step12 - Then click on the NEXT button. Step5
(If the problem persists until after above steps have been taken, please
contact our C/S.)
Error Code $0011 Link
Step Message
E - Rear feeder unlock sensor is sensed.
Step1 1. Press the STOP button. (Stop the buzzer sound).
Step2 - Open the equipment door.
Step3 - Check if there are any loose feeders on the rear feeder lane.
. Yes, there are loose feeders. Step4
. No, there is no loose feeder. Step11
- Then click on the NEXT button.
Step4 - Secure the feeders completely.
- Then click on the NEXT button.
Step5 - Close the equipment door.
Step6 1. Press the RESET button.
2. Turn on the power for MOTOR.
3. Press the READY button.
- Click on the NEXT button.
Step7 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step8 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step9 - Press the START button to resume operation.
Step11 - Check the following.
… Check the connecting condition of the sensor and the reception and
dispatch positions.
… Check if there is any contaminant, such as vinyl or components, on
the feeder.
… In the case of vibratory feeder, check if components are stacked up.
Step12 - Then click on the NEXT button. Step5
(If the problem persists until after above steps have been taken, please
contact our C/S.)
Error Code $0020 Link
Step Message
E - The front door is open.
Step1 1. Close the front door completely once more.
2. Press the STOP button. (Stop the buzzer sound).
3. Press the RESET button.
4. Press the READY button.
- Then click on the NEXT button.
Step2 1. Turn on the power for MOTOR.
2. Select the HOME mode by using the MODE button in the teaching box.
