Samsung Component Placer CP-45F(V)/FS Operations Manual
B-32
Step5 - Is there any physical interference?
. Yes, there is. Step6
. No, there isn't. Step13
- Then click on the NEXT button.
Step6 - Remove the physical interference.
- Then click on the NEXT button.
Step7 - Close the equipment door.
Step8 1. Cancel by turning the emergency switch.
2. Press the RESET button.
- Then click on the NEXT button.
Step9 1. Turn on the power for motor.
2. Press the READY button.
- Then click on the NEXT button.
Step10 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step11 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step12 - Press the START button to resume operation.
Step13 - Please contact Our C/S.
Error Code $2002 Link
Step Message
E - Can't lower the BUT(Backup Table).
Step1 1. Press the STOP button. (Stop the buzzer sound).
Step2 - Open the equipment door.
Step3 - Move the BUT from the I/O menu of MMI Diagnosis .
Does the BUT(Backup Table) move? Step4
. Yes, the BUT moves. Step5
. No, the BUT does not move.
Then click on the NEXT button
Step4 - There is a problem with the sensor
- Please contact Our C/S.
Step5 - Is there any physical interference?
. Yes, there is. Step6
. No, there isn't. Step13
- Then click on the NEXT button.
Step6 - Remove the physical interference.
- Then click on the NEXT button.
Step7 - Close the equipment door.
Step8 1. Cancel by turning the emergency switch.
2. Press the RESET button.
- Then click on the NEXT button.
Step9 1. Turn on the power for motor.
2. Press the READY button.
- Then click on the NEXT button.
Step10 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
Appendix B 3D Trouble Shooting Guide
B-33
3. Press the HOME START button.
- Then click on the NEXT button.
Step11 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step12 - Press the START button to resume operation.
Step13 - Please contact Our C/S.
Error Code $3101 Link
Step Message
E - PCB did not arrive at the waiting sensor area.
Step1
- Check the problem and choose the corresponding problem in the figure
above.
. When the problem is (a) or (b). Step3
. When the problem is (c) Step12
Step2 1. Press the STOP button. (Stop the buzzer).
Step3 - Open the equipment door.
Step4 - Manually remove the PCB.
- Then click on the NEXT button.
Step5
- Adjust the conveyor width from the Board setting in the PCB menu of
MMI.
Step6 - Close the equipment door.
Step7 1. Cancel by turning the emergency switch.
2. Press the RESET button.
- Then click on the NEXT button.
Step8 1. Turn on the power for motor.
2. Press the READY button.
- Then click on the NEXT button.
Step9 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step10 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step11 - Press the START button to resume operation.
Step12 - Please contact Our C/S.
Error Code $3102 Link
Step Message
E - The PCB did not arrive at the mounting sensor area.
Step1
- Check the problem and choose the corresponding problem in the figure
above.
. When the problem is (a) or (b). Step3
. When the problem is (c) Step12
Step2 1. Press the STOP button. (Stop the buzzer sound).
Step3 - Open the equipment door.
Step4 - Manually remove the PCB.
- Then click on the NEXT button.
Step5 - Adjust the conveyor width from the Board setting in the PCB menu of
Samsung Component Placer CP-45F(V)/FS Operations Manual
B-34
MMI.
Step6 - Close the equipment door.
Step7 1. Cancel it by turning the emergency switch.
2. Press the RESET button.
- Then click on the NEXT button.
Step8 1. Turn on the power for motor.
2. Press the READY button.
- Then click on the NEXT button.
Step9 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step10 - Click on START or CONTINUE on MMI
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step11 - Press the START button to resume operation.
Step12 - Please contact Our C/S.
Error Code $3103 Link
Step Message
E - The PCB did not arrive at the output sensor area.
Step1
- Check the problem and choose the corresponding problem in the figure
above.
. When the problem is (a) or (b). Step3
. When the problem is (c) Step12
Step2 1. Press the STOP button. (Stop the buzzer sound).
Step3 - Open the equipment door.
Step4 - Manually remove the PCB.
- Then click on the NEXT button.
Step5
- Adjust the conveyor width from the Board setting in the PCB menu of
MMI.
Step6 - Close the equipment door.
Step7 1. Cancel by turning the emergency switch.
2. Press the RESET button.
- Then click on the NEXT button.
Step8 1. Turn on the power for motor.
2. Press the READY button.
- Then click on the NEXT button.
Step9 1. Select the HOME mode by using the MODE button in the teaching box.
2. Turn off all the LEDs by using the AXIS button.
3. Press the HOME START button.
- Then click on the NEXT button.
Step10 - Click on START or CONTINUE on MMI.
… 'START': starts operation with a new PCB.
… 'CONTINUE': continues at the point where the operation stopped.
Step11 - Press the START button to resume operation.
Step12 - Please contact Our C/S.
Error Code $3104 Link
Step Message
