Samsung Component Placer CP-45F(V)/FS Operations Manual B-30 (b) Feeder error Step5 (c) Other. Step6 Step4 - Specify the component pickup position for the feeder and resum e operation. Step5 - Solve the problem of the f …
Appendix B 3D Trouble Shooting Guide
B-29
Stpe4 - Press the START button to resume operation.
Error Code $4301Z Link
Step Message
E The Z axis is sensed in the (+) S/W Limit by using the Jog Box.
Step1 - Press the STOP button. (Stop the buzzer sound).
Step2 - Move the Z axis to a position in the S/W Limit by using the teaching box.
- Then click on the NEXT button.
Step3 - Check the setting from the Limits item in the System menu of MMI.
Stpe4 - Press the START button to resume operation.
Error Code $5101 Link
Step Message
E - An error in the number of retries occurred at the Tape Feeder.
Step1 - Press the STOP button. (Stop the buzzer sound).
Step2 - Check if there are components in the corresponding feeder.
Step3 . Yes, there are components left. Step4
. No, there is no component left. Step11
- Then click on the NEXT button.
Step4 - Choose the current situation from above figure.
. (a) Pickup position error Step5
. (b) Vinyl cover is not completely taken off. Step6
. (c) Deviated pitch. Step7
. (d) Feeder error. Step8
. (e) Other. Step10
Step5
- Specify the component pickup position for the feeder again and resume
operation.
Step6 - Take off the vinyl and resume operation.
Step7 - Adjust the pitch and resume operation.
Step8 - Install the feeder securely.
- Then click on the NEXT button. Step9
Step9 - Press the START button to resume operation.
Step10 - Please contact Our C/S.
Step11 - Supply components and resume operation.
Error Code $5300 Link
Step Message
E - There is no component in the Tray feeder.
- Supply components and resume operation.
Error Code $5201 Link
Step Message
E - An error in the number of retries occurred at the Stick Feeder.
Step1 - Press the STOP button. (Stop the buzzer sound).
Step2 - Check if there are any components in the corresponding feeder.
. Yes, there are components left. Step3
. No, there is no component left.
- Then click on the NEXT button.
Step3 - Check the problem and choose one of the following items.
(a) X,Y position error. Step4
Samsung Component Placer CP-45F(V)/FS Operations Manual
B-30
(b) Feeder error Step5
(c) Other. Step6
Step4
- Specify the component pickup position for the feeder and resume
operation.
Step5 - Solve the problem of the feeder and resume operation.
Step6 - Please contact Our C/S.
Step7 - Supply components again and resume operation.
Error Code $4200 Link
Step Message
E - Tried to pickup a component on a position that is beyond the limit.
Step1 - Please contact our C/S.
Error Code $4201 Link
Step Message
E - Tried to place a component on a position that is beyond the limit.
Step1 - Please contact out C/S .
Error Code $4202 Link
Step Message
E - Tried to change nozzle on a position that is beyond the limit.
Step1 - Please contact our C/S.
Error Code $5301 Link
Step Message
E - A error in the number of retries at Tray Feeder.
- Pressing the START button could resume operation.
- If the problem persists, check the following.
… Check if there are components
… Component pickup position
… Level of flatness of the tray
Error Code $5501 Link
Step Message
E - Tray feeder is in error.
Step1
- Check the error message on the LCD screen of tray feeder and solve the
problem.
Step2 - Press the STOP button. (Stop the buzzer sound).
Error Code $5502 Link
Step Message
E - Tray feeder is not ready.
Step1
- Check the error message on the LCD screen of tray feeder and solve the
problem.
Step2 - Press the STOP button. (Stop the buzzer sound).
Error Code $5503 Link
Step Message
E - Error in the tray feeder communication command.
Step1 - Check the error message on the LCD screen of tray feeder and solve the
Appendix B 3D Trouble Shooting Guide
B-31
problem.
Step2 - Press the STOP button. (Stop the buzzer sound).
Error Code $5504 Link
Step Message
E - Error in the tray feeder communication data.
Step1
- Check the error message on the LCD screen of tray feeder and solve the
problem.
Step2 - Press the STOP button. (Stop the buzzer sound).
Error Code $5505 Link
Step Message
E - No palette in the tray feeder.
Step1
- Check the error message on the LCD screen of tray feeder and solve the
problem.
Step2 - Press the STOP button. (Stop the buzzer sound).
Error Code $5506 Link
Step Message
E - Time out error in the tray feeder.
Step1
- Check the error message on the LCD screen of tray feeder and solve the
problem.
Step2 - Press the STOP button. (Stop the buzzer sound).
Error Code $5800 Link
Step Message
E - Vacuum Check error.
- Check the following and resume operation.
… Component pickup condition check
… Nozzle wear condition check
… Vacuum Generator check
- If the problem persists, please contact Our C/S.
Error Code $5801 Link
Step Message
E - Vision Check error.
- Check the vision related setting of the component.
Error Code $2001 Link
Step Message
E - Can't raise the BUT(Backup Table).
Step1 1. Press the STOP button. (Stop the buzzer sound).
Step2 - Open the equipment door.
Step3 - Move the BUT from the I/O menu of MMI Diagnosis.
Does the BUT(Backup Table) move?
. Yes, the BUT moves. Step4
. No, the BUT does not move. Step5
- Then click on the NEXT button.
Step4 - There is a problem with the sensor.
- Please contact Our C/S.
