24mm S-Pneumatic Feeder Q'TY 8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm 28 J1301606 BEARING FC-4K (NSK) 29 J2500009 STEEL BALL SPRING TF08-011 30 J2500024 SPRING HOOK PIN TF08-029 31 J2500058 REEL PL…
24mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
1
J7000885
SHUTTER LEVER ASS'Y
0 0 0 0 1 1 1 1 0
2
J7000788 TAPE GUIDE ASS'Y 0 0 0 0 1 0 0 0 0
3
J7000796 SPROCKET ASS'Y 0 0 0 0 1 0 0 0 0
4
J7000802
PUSHER LEVER ASS'Y
0 0 0 0 1 0 0 0 0
5
J7000809
REEL WIND LEVER ASS'Y
0 0 1 1 1 1 1 1 1
6
J7000812
PITCH LINK ASS'Y
0 0 0 0 1 0 0 0 0
7
J7000814
MANUAL LEVER ASS'Y
0 0 1 1 1 1 1 1 1
8
J7000816
CLAMP LEVER 1 ASS'Y
0 0 0 0 1 1 1 1 1
9
J7000819
CLAMP LEVER 2 ASS'Y
0 0 0 0 1 0 0 0 0
10
J7000824 SPROCKET LEVER ASS'Y 0 0 0 0 1 1 1 1 0
11
J7000827
CROSS LEVER ASS'Y
0 0 0 0 1 1 1 1 1
12
J7000829
CROSS LEVER LINK ASS'Y
0 0 0 0 1 1 1 1 1
13
J7000832
REWIND LEVER ASS'Y
0 0 0 0 1 1 1 1 1
14
J7000835
LINK 2 ASS'Y
0 0 0 0 1 1 1 1 1
15
J7000888
TAKE UP REEL PLATE ASS'Y
0 0 0 0 1 1 1 1 0
16
J7000891
REEL ARM PLATE ASS'Y
0 0 1 1 1 1 1 1 0
17
18
19
20
J1301025
E-RING
DIA12 (SUS)
21
J1301154
FLAT WASHER
M3 (SUS)
22
J1301155
STEEL BALL
DIA4 (NSK)
23
J1301157
FLAT HEAD CAP SCREW
M4*10 (SUS)
24
J1301222
FLAT HEAD CAP SCREW
M3*4 (SUS)
25
J1301308
TENSION SPRING
AWS5-30
26
J1301309
CLAMP SPRING
E658 (ULTRA
27
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
REMARKNO. PART NO. PART NAME TYPE
- D-3 -
24mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
28
J1301606
BEARING
FC-4K (NSK)
29
J2500009
STEEL BALL SPRING
TF08-011
30
J2500024
SPRING HOOK PIN
TF08-029
31
J2500058
REEL PLATE PIN
TF08-065
32
33
J2500158
TAPE BRAKE
TF12-020
34
J2500159
TAPE BRAKE SHAFT
TF12-021
35
J2500160
SPRING HOOK PIN
TF12-022
36
J2500172
RELEASE PIN
TF12-094
37
J2500175
BACKUP GUIDE SCREW
TF44-017
38
J2500178
CLAMP SPRING PIN 2
TF44-045
39
J2500199
BACKUP SPRING
TF44-084
40
J7065234B
RATCHET PAWL
TF16-009R
41
J2500237
SHUTTER LEVER
TF16-091R
42
J7065258B
TAPE GUIDE SHAFT
J7065258B
43
J2500241
VINYL GUIDE ROLLER SHAFT
TF24-011
44
J2500242
VINYL GUIDE ROLLER
TF24-012
45
J2500243
LOCKER
TF24-013R
46
J2500244
LOCKER SHAFT
TF24-014
47
J2500246
SPROCKET SHAFT
TF24-019R
48
J2500250
PUSHER ROLLER
TF24-033R
49
J2500252
CLAMP LEVER PIN
TF24-041
50
J2500253
TAKE UP REEL SHAFT
TF24-049R
51
J2500254
REEL ARM POST
TF24-066
52
J2500258
PUSHER SUPPORT PLATE
TF24-079
53
J2500263
LOCKER SPACER
TF24-088
54
J2500264
TAPE GUIDE SPRING
TF44-010
REMARKNO. PART NO. PART NAME TYPE
- D-4-
24mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
55
J2500268
PUSHER LEVER 2
TF44-031
56
J2500273
CLAMP SPRING PIN 1
TF44-043
57
J2500274
REEL WIND PAWL SPRING
TF44-052R
58
J2500283
RATCHET PAWL SPRING
TF44-075
59
J2500448
PLANET GEAR
TF08-100K
60
J2500462
FIXED TAKE UP REEL
TF24-077K
61
J2500465
REEL PAWL SHAFT
TF12-044K
62
J2500481
MAIN FRAME
TF24-005R2
63
J2500511
REMOVABLE TAKE UP REEL
TF24-076K
64
J2500517
STEEL BALL SPRING 2
TF24-080R
65
J7065176B
CLAMP LINK
J7065176B
66
J7065180B
REEL ARM PLATE
J7065180B
67
J7065271B
REEL PAWL SPRING
TF24-061R2
68
J7065281B
REWIND SPRING
TF24-089R3
69
J7065323B
HOOK LINK
J7065323B
70
71
72
73
74
75
76
77
78
79
80
81
REMARKNO. PART NO. PART NAME TYPE
- D-5 -
