12mm N-Pneumatic Feeder Q'TY 12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N 28 J7165286A PUSHER SUPPORT TF12-N079 29 J7065925A FEEDING SPRING TF12-N065R1 30 J7065118A LEVER CENTER SCREW TF08-033 31 J706…
12mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
1
J7265130A VINYL GUIDE ROLLER
TF12-N012
2
J7065748A
VINYL GUIDE ROLLER SHAFT TF12-N011
3
J7065747A
TAPE GUIDE SHAFT TF12-N009
4
J7065750A
LOCKER SHAFT TF12-N014R1
5
J7065767A
LOCKER SPACER TF12-N088
6
J7065809A
TAKE UP REEL SHAFT
TF12-N240
7
J7265135A
FIXED TAKE UP REEL
TF12-N248R
8
J7265070A
REMOVABLE TAKE UP REEL
TF12-076K
9
J7065810A
REEL ARM POST
TF12-N241
10
J7065751A TAPE SUPPORT TF12-N016R2
11
J7065752A
TAPE SUPPORT SCREW
TF12-N017
12
J7065763A
FEEDING SPRING BRACKET
TF12-N073R2
13
J7065764A
PITCH CHANGE SCREW
TF12-N077R2
14
J7065769A
ECCENTRIC SHAFT 2
TF12-N101
15
J7065775B
TAPE GUIDE PLATE
TF12-N139R
16
J7065776B
TAPE COVER PLATE
TF12-N140R3
17
J7065936A
TAPE BRAKE
TF12-N209R1
18
J7265131A
DAMPER
TF12-N226R
19
J7065802A
DAMPER WASHER
TF12-N228R
20
J7065804C
REEL GUIDE
TF12-N230R1
21
J7065805A
HOOK LINK
TF12-N231
22
J7265132A
DRAIN GEAR-L
TF12-N235
23
J7065813A
REWIND SPRING
TF12-N252R2
24
J7065814A
DRAIN BRACKET
TF12-N253
25
J7265136B
HANDLE
TF12-N257R3
26
J7065819B
CLAMP LEVER PIN
TF16-N041R
27
J7065756A
PUSHER LEVER 1
TF12-N030R
REMARKNO. PART NO. PART NAME TYPE
- B-16 -
12mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
28
J7165286A PUSHER SUPPORT
TF12-N079
29
J7065925A
FEEDING SPRING TF12-N065R1
30
J7065118A
LEVER CENTER SCREW TF08-033
31
J7065088A
IDLER GEAR TF08-Q112
32
J7065176A
CLAMP LINK TF12-014R
33
J7065198A
SPROCKET SHAFT
TF12-057
34
J7065199A
REEL PAWL SPRING
TF12-061K
35
J7065234B
RATCHET PAWL
TF16-009R
36
J7065929A
PITCH PAWL
TF12-N028
37
J7065331A REEL WIND PAWL SPRING TF44-052R
38
J7065127A
FEEDING SPRING GUIDE
TF44-074
39
J7065340A
RATCHET PAWL SPRING
TF44-075
40
J7065530A
PITCH PAWL SPRING
TF08-020R1
41
J7065347A
ECCENTRIC SHAFT
TF44-091R
42
J7065350A
LEVER SHAFT 1
TF44-107R
43
J7065196A
PUSHER ROLLER
TF12-055R
44
J7065504A
DRAIN PAWL SPRING
TF08-Q153
45
J9065079A
MAIN FRAME ASS'Y
J9065079A
45-1
J7165258A MAIN FRAME
TF12-N001R2
45-2
J7165260A PUSHER LEVER BUSH 1
TF12-N072
45-3
J7065151A LOCATION PIN
TF08-075R
45-4
J7065423A
LOCATION PIN TF08-075R1
45-5 J7065158A
PIN SPACER 2 TF08-093
REMARKNO. PART NO. PART NAME TYPE
- B-17 -
12mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
J6107013A TENSION SPRING
AWS5-30
J6107014A
CLAMP SPRING E658
J6071200050
E-RING DIA2 (SUS)
J6071300050
E-RING DIA3 (SUS)
J6071400050
E-RING DIA4 (SUS)
J6071500050
E-RING
DIA5 (SUS)
J6071700050
E-RING
DIA7 (SUS)
J607020050
E-RING
DIA12 (SUS)
J6073020050
C-RING(SHAFT)
DIA12 (SUS)
J6025300050 HEX NUT M3 (SUS)
J6025400050
HEX NUT
M4 (SUS)
J6025500050
HEX NUT
M5 (SUS)
J6042400050
FLAT WASHER
M4 (SUS)
J6042500050
FLAT WASHER
M5 (SUS)
J6043400050
SPRING WASHER
M4 (SUS)
J6043500050
SPRING WASHER
M5 (SUS)
J6044300050
STAR WASHER
M3 (SUS)
J6006300650
FLAT HEAD CAP SCREW
M3*6 (SUS)
J6006401050
FLAT HEAD CAP SCREW
M4*10(SUS)
J6004300350
BUTTON HEAD CAP SCREW
M3*3 (SUS)
J6007300850
FLAT HEAD SOCKET SCREW
M3*8 (SUS)
REMARKNO. PART NO. PART NAME TYPE
- B-18 -
