56mm N-Pneumatic Feeder Q'TY 12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N 28 J7065908C REEL GUIDE TF56-N230R4 29 J7265150B DRAIN GEAR TF56-N236R3 30 J7065909A TAKE UP REEL SHAFT TF56-N240 31 J7065910A…
56mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
1
J7065792A LINK PIN
TF12-N217
Deletion
2
J7065752A TAPE SUPPORT SCREW
TF12-N017
3
J7065763A
FEEDING SPRING BRACKET TF12-N073R2
4
J7065764A
PITCH CHANGE SCREW TF12-N077R2
5
J7065769A
ECCENTRIC SHAFT 2 TF12-N101
6
J7065785A
TAPE BRAKE TF12-N209
7
J7265131A
DAMPER
TF12-N226R
8
J7065802A
DAMPER WASHER
TF12-N228R
9
J7265136B
HANDLE
TF12-N257R3
10
J7065834A
PUSHER LEVER 1
TF24-N030R
11
J7165269A PAWL LEVER TF24-N211R2
12
J7065843A
REEL PAWL 1 SHAFT
TF24-N212R2
13
J7065847A
FORMING SHAFT
TF24-N239
14
J7065852B
DRAIN PAWL SPRING
TF24-N249R4
15
J7065853A
REWIND SPRING
TF24-N250R2
16
J7065854A
PAWL LEVER PIN
TF24-N256R2
17
J7065896B
TAPE GUIDE
TF56-N008R1
18
J7065897A
TAPE GUIDE SHAFT
TF56-N009
19
J7065898A
VINYL GUIDE ROLLER SHAFT
TF56-N011
20
J7265149A
VINYL GUIDE ROLLER
TF56-N012
21
J7065899A
LOCKER SHAFT
TF56-N014
22
J7065900A
TAPE SUPPORT
TF56-N016R
23
J7065903A
PUSHER ROLLER
TF56-N033
24
J7065904A
CLAMP LEVER PIN
TF56-N041
25
J7165279A
PUSHER SUPPORT
TF56-N079R
26
J7065906A
LOCKER SPACER
TF56-N088
27
J7165280A
TAPE GUIDE BLOCK
TF56-N140R
REMARKNO. PART NO. PART NAME TYPE
- G-16 -
56mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
28
J7065908C REEL GUIDE
TF56-N230R4
29
J7265150B DRAIN GEAR
TF56-N236R3
30
J7065909A
TAKE UP REEL SHAFT TF56-N240
31
J7065910A
REEL ARM POST TF56-N241
32
J7065912B
COVER TAPE CHUTE TF56-N245R
33
J7265151A
FIXED TAKE UP REEL TF56-N248R
34
J7165282B
PAWL LEVER BLOCK
TF56-N255R4
35
J7065907A
STAY BAR
TF56-N139
36
J7065926A
FEEDING SPRING
TF24-N065R2
37
J7065118A
LEVER CENTER SCREW
TF08-033
38
J7065176A CLAMP LINK TF12-014R
39
J7065234B
RATCHET PAWL
TF16-009R
40
J7065929A
PITCH PAWL
TF12-N028
41
J7065323A
HOOK LINK
TF44-039
42
J7065331A
REEL WIND PAWL SPRING
TF44-052R
43
J7065127A
FEEDING SPRING GUIDE
TF44-074
44
J7065340A
RATCHET PAWL SPRING
TF44-075
45
J7065530A
PITCH PAWL SPRING
TF08-020R1
46
J7065347A
ECCENTRIC SHAFT
TF44-091R
47
J7065350A
LEVER SHAFT 1
TF44-107R
48
J7065310A
SPROCKET FIXING SCREW
TF44-024
49
J9065128A MAIN FRAME ASS'Y J9065128A
49-1
J7165271A MAIN FRAME
TF32-N001R2
49-2
J7165281A SPROCKET SHAFT BLOCK
TF56-N141
49-3
J7165103A SPROCKET SHAFT BUSH
TF44-020
49-4
J7165260A PUSHER LEVER BUSH 1
TF12-N072
49-5
J7065151A LOCATION PIN
TF08-075R
49-6
J7065423A LOCATION PIN TF08-075R1
49-7 J7065158A
PIN SPACER 2 TF08-093
REMARKNO. PART NO. PART NAME TYPE
- G-17 -
56mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
50 J9065106A
SUB FRAME ASS'Y
J9065106A
50-1
J7165259A
SUB FRAME
TF24-N002R2
50-2
J7165266A
PUSHER LEVER BUSH 2
TF24-N072
51 J7065935A CHUTE BLADE
TF24-N254
J6107013A TENSION SPRING
AWS5-30
J6107014A CLAMP SPRING
E658
J6071200050
E-RING DIA2 (SUS)
J6071300050
E-RING DIA3 (SUS)
J6071400050
E-RING DIA4 (SUS)
J6071500050
E-RING DIA5 (SUS)
J607020050
E-RING
DIA12 (SUS)
J6073020050
C-RING(SHAFT)
DIA12 (SUS)
J6025300050
HEX NUT
M3 (SUS)
J6025400050
HEX NUT
M4 (SUS)
J6025500050 HEX NUT M5 (SUS)
J6042400050
FLAT WASHER
M4 (SUS)
J6042500050
FLAT WASHER
M5 (SUS)
J6043400050
SPRING WASHER
M4 (SUS)
J6043500050
SPRING WASHER
M5 (SUS)
J6044300050
STAR WASHER
M3 (SUS)
J6006300650
FLAT HEAD CAP SCREW
M3*6 (SUS)
J6006401050
FLAT HEAD CAP SCREW
M4*10 (SUS)
J6004300350
BUTTON HEAD CAP SCREW
M3*3 (SUS)
J6004303250
BUTTON HEAD CAP SCREW
M3*32 (SUS)
J6005402050
BUTTON HEAD CAP SCREW
M4*20 (SUS)
J6007300850
FLAT HEAD SOCKET SCREW
M3*8 (SUS)
J1301161
FLAT HEAD CAP SCREW
M2*3 (SUS)
REMARKNO. PART NO. PART NAME TYPE
- G-18 -
