0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E) 22 J1300468 SPRING WASHER M3 23 J1301023 E-RING DIA3 (SUS) 24 J1301151 HEX NUT M6 (SUS) 25 J1301154 FLAT WASHER M3 (SUS) 26 J1301155 STEEL BALL DIA4 (NSK) 27 J1301157 FLAT HEAD CAP …

100%1 / 241
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
1
J7000773 SPROCKET ASS'Y 1 1 1 1 1 1
4mm Pitch
J8100120A SPROCKET ASS'Y 1 1 1 1 1 1
2mm Pitch
2
J8100123A TAPE GUIDE ASS'Y 0 0 0 0 1 1
3
J7000775
PUSHER LEVER ASS'Y
1 1 1 1 1 1
4
J7000776
SHUTTER LEVER ASS'Y
1 1 1 1 1 1
5
J7000777
RACHET PUSHER ASS'Y
0 0 0 1 1 1
6
J7000778
REEL WIND CLANK ASS'Y
1 1 1 1 1 1
7
J7000779
MANUAL LEVER LINK ASS'Y
1 1 1 1 1 1
8
J7000776
REWIND LINK ASS'Y
1 1 1 1 1 1
9
J8100129A
TAKE UP REEL PLATE ASS'Y
1 0 0 0 1 1
10
J7165144B
MAIN FRAME
1 1 1 0 1 1
J7165190C
MAIN FRAME
1 1 1 0 1 1 TF08-Q167 NST-08E-2P
J7165191C
MAIN FRAME
1 1 1 0 1 1 TF08-Q134E NST-08E-4P
11
J8100125A
CLAMP ARM ASS'Y
0 1 1 0 1 1 RED 2mm Pitch
J8100126A
CLAMP ARM ASS'Y
0 0 0 0 1 1 BLUE 4mm Pitch
12
J8100127A
CLAMP BAR ASS'Y
1 1 1 0 1 1
13
J8100128A
FORMING BRAKET ASS'Y
1 1 1 0 1 1
14
J8100130A
REEL ARM PLATE ASS'Y
0 0 0 0 1 1
J8100131A
REEL ARM PLATE ASS'Y
0 0 0 0 1 1 Non Stop L Type
15
J8100124A
SPRING BRAKET ASS`Y
1 1 1 0 1 1
16
J8100133A
POCKET ASS`Y
0 0 1 0 1 1 2mm Pitch
J8100132A
POCKET ASS`Y
0 0 0 0 0 1 4mm Pitch
18
J7265088B
IDLER GEAR
TF08-Q112R
19
J7265089B
DRAIN GEAR-L
TF08-Q113R
20
J1301152
SPRING PIN
PHI2*8 (SUS)
21
J600430035
FLAT HEAD CAP SCREW
M3*3 (SUS)
TYPE REMARK
8mm N, N(E)-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 27
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
22
J1300468
SPRING WASHER
M3
23
J1301023
E-RING
DIA3 (SUS)
24
J1301151
HEX NUT
M6 (SUS)
25
J1301154
FLAT WASHER
M3 (SUS)
26
J1301155
STEEL BALL
DIA4 (NSK)
27
J1301157
FLAT HEAD CAP SCREW
M4*10 (SUS)
28
29
J1301161
FLAT HEAD CAP SCREW
M2*3 (SUS)
30 J7065744A
TAPE SUPPORT
TF08-Q169R2
NST-08E-4P
31
32
J1301164
BEARING
MR84zz (NSK)
33
J1301266
HEX NUT
M3 (SUS)
34
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
35
36 J2500009
STEEL BALL SPRING
TF08-011
37 J7065547A
LOCKER SHAFT
TF08-Q158
38 J2500016
PITCH PAWL
TF08-019R
39
40 J2500028
LEVER CENTER SCREW
TF08-033
41 J2500036
FEEDING SPRING GUIDE
TF08-042R
42 J2500037
FEEDING SPRING BRACKET
TF08-043
43 J2500038
CLAMP LEVER
TF08-044
44 J7065491A
CLAMP SPRING
TF08-Q140
45 J2500040
CLAMP SPRING GUIDE
TF08-046
46 J2500043
MANUAL LEVER
TF08-050
47 J7065482A
REEL LINK
TF08-129
48 J7065477D
REEL ARM PLATE
TF08-Q123R2
TYPE REMARK
8mm N, N(E)-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 28
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
49
50 J2500061 VINYL GUIDE ROLLER SHAFT 2
TF08-068R
51 J7265091B VINYL GUIDE ROLLER 2
TF08-Q115R
52 J7065147C
TAPE COVER
TF08-070R1
53 J2500064
REWIND LINK SCREW
TF08-071
54 J1301448
FLAT HEAD CAP SCREW
M3*6(SUS)
55 J2500067
REWIND SPRING
TF08-074
56 J2500068
LOCATION PIN
TF08-075R
57 J7065153B
PUSHER LEVER GUIDE
TF08-077R
58 J2500078
RACHET PUSHER SPRING
TF08-030R
59 J2500457
PITCH PAWL SPRING
TF08-020J
S1005
J2500434
PITCH PAWL SPRING
TF08-020R2
S1608
60 J2500212
STOPPER PIN
TF08-028R1
61 J2500392
ECCENTRIC SHAFT
TF08-021R1
62
63 J2500415
MANUAL LEVER SPRING
TF08-051R2
64 J2500416
PIN SPACER 2
TF08-093
65
66 J2500418
LEVER RETURN SPRING
TF08-041R1
67 J7065488C LOCKER TF08-Q137R1
68 J7265078B
FIXED TAKE UP REEL
TF08-062KA1
69 J7265046B
REMOVABLE TAKE UP REEL
TF08-063K1
70 J7065432A
DRAIN WIND PAWL SPRING
TF08-P55K
71
J2500407
LEVER CENTER SCREW
TF08-033R2
72 J7265075B PLANET GEAR B TF08-100KA1
73 J2500525
PLANET SPRING
TF08-104KA
TYPE REMARK
8mm N, N(E)-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 29
