CP,SM Tape Feeder Total CS Manual(V200603).pdf - 第19页
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E) 50 J2500061 VINYL GUIDE ROLLER TF08-068R 51 J7265091B VINYL GUIDE ROLLER 2 TF08-Q115R 52 J7065147C TAPE COVER TF08-070R1 53 J2500064 RE W IND LINK SCREW TF08-071 54 J1301448 FLAT HE…
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
23
J1301023 E-RING
DIA3 (SUS)
24
J1301151 HEX NUT
M6 (SUS)
25
J1301154 FLAT WASHER
M3 (SUS)
26
J1301155
STEEL BALL DIA4 (NSK)
27
J1301157
FLAT HEAD CAP SCREW M4*10 (SUS)
28
29
J1301161
FLAT HEAD CAP SCREW
M2*3 (SUS)
30
J7065744A
TAPE SUPPORT
TF08-Q169R2
NST-08E-4P
31
32
J1301164
BEARING
MR84zz (NSK)
33
J1301266
HEX NUT
M3 (SUS)
34
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
35
36
J2500009
STEEL BALL SPRING
TF08-011
37
J7065547A
LOCKER SHAFT
TF08-Q158
38
J2500016
PITCH PAWL
TF08-019R
39
40
J2500028
LEVER CENTER SCREW
TF08-033
41
J2500036
FEEDING SPRING GUIDE
TF08-042R
42
J2500037
FEEDING SPRING BRACKET
TF08-043
43
J2500038
CLAMP LEVER
TF08-044
44
J7065491A
CLAMP SPRING
TF08-Q140
45
J2500040
CLAMP SPRING GUIDE
TF08-046
46
J2500043
MANUAL LEVER
TF08-050
47
J7065482A
REEL LINK
TF08-129
48
J7065477D
REEL ARM PLATE
TF08-Q123R2
49
TYPE REMARK
1005N-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 16
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
50
J2500061 VINYL GUIDE ROLLER
TF08-068R
51
J7265091B VINYL GUIDE ROLLER 2
TF08-Q115R
52
J7065147C TAPE COVER
TF08-070R1
53
J2500064
REWIND LINK SCREW TF08-071
54
J1301448
FLAT HEAD CAP SCREW M3*6(SUS)
55
J2500067
REWIND SPRING
TF08-074
56
J2500068
LOCATION PIN
TF08-075R
57
J7065153B
PUSHER LEVER GUIDE
TF08-077R
58
J2500078
RACHET PUSHER SPRING
TF08-030R
59
J2500457
PITCH PAWL SPRING
TF08-020J
S1005
J2500434
PITCH PAWL SPRING
TF08-020R2
S1608
60
J2500212
STOPPER PIN
TF08-028R1
61
J2500392
ECCENTRIC SHAFT
TF08-021R1
62
63
J2500415
MANUAL LEVER SPRING
TF08-051R2
64
J2500416
PIN SPACER 2
TF08-093
65
66
J2500418
LEVER RETURN SPRING
TF08-041R1
67
J7065488C
LOCKER
TF08-Q137R1
68
J7265078B
FIXED TAKE UP REEL
TF08-062KA1
69
J7265046B
REMOVABLE TAKE UP REEL
TF08-063K1
70
J7065432A
DRAIN WIND PAWL SPRING
TF08-P55K
71
J2500407
LEVER CENTER SCREW
TF08-033R2
72
J7265075B
PLANET GEAR B
TF08-100KA1
73
J2500525
PLANET SPRING
TF08-104KA
74
J7265076B
PLANET LEVER
TF08-102KA1
TYPE REMARK
1005N-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A -17
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
75
J7065423A LOCATION PIN
J7065423A
76
J7265087A FPRMING GEAR2
TF08-P120
77
J7065499A LOCKER SPRING
TF08-Q148
J7065563A
LOCKER SPRING TF08-Q163
NST-08E-2P
J7065566A
LOCKER SPRING TF08-Q164
NST-08E-4P
78
79
J7065497A
CLAMP LINK
TF08-Q146
80
J7065501A
CLAMP SHAFT
TF08-Q150
81
82
J7065502A
DRAIN PAWL SPRING
TF08-Q151
NST1005
J7065504A
DRAIN PAWL SPRING
TF08-Q153
NST08
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
TYPE REMARK
1005N-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A -18
