32mm N-Pneumatic Feeder Q'TY 12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N 28 J7265144B DRAIN GEAR TF32-N236R3 29 J7065869A TAKE UP REEL SHAFT TF32-N240 30 J7065870A REEL ARM POST TF32-N241 31 J7065872…
32mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
1
J7065792A LINK PIN
TF12-N217
Deletion
2
J7065752A TAPE SUPPORT SCREW
TF12-N017
3
J7065763A
FEEDING SPRING BRACKET TF12-N073R2
4
J7065764A
PITCH CHANGE SCREW TF12-N077R2
5
J7065769A
ECCENTRIC SHAFT 2 TF12-N101
6
J7065785A
TAPE BRAKE TF12-N209
7
J7265131A
DAMPER
TF12-N226R
8
J7065802A
DAMPER WASHER
TF12-N228R
9
J7265136B
HANDLE
TF12-N257R3
10
J7065834A
PUSHER LEVER 1
TF24-N030R
11
J7165269A PAWL LEVER TF24-N211R2
12
J7065843A
REEL PAWL 1 SHAFT
TF24-N212R2
13
J7065847A
FORMING SHAFT
TF24-N239
14
J7065852B
DRAIN PAWL SPRING
TF24-N249R4
15
J7065853A
REWIND SPRING
TF24-N250R2
16
J7065854A
PAWL LEVER PIN
TF24-N256R2
17
J7065856A
TAPE GUIDE SHAFT
TF32-N009
18
J7065857A
VINYL GUIDE ROLLER SHAFT
TF32-N011
19
J7265143A
VINYL GUIDE ROLLER
TF32-N012
20
J7065858A
LOCKER SHAFT
TF32-N014
21
J7065859A
TAPE SUPPORT
TF32-N016R
22
J7065862A
PUSHER ROLLER
TF32-N033
23
J7065863A
CLAMP LEVER PIN
TF32-N041
24
J7165272A
PUSHER SUPPORT
TF32-N079R
25
J7065866A
LOCKER SPACER
TF32-N088
26
J7165273A
TAPE GUIDE BLOCK
TF32-N140R
27
J7065868C
REEL GUIDE
TF32-N230R4
REMARKNO. PART NO. PART NAME TYPE
- E-18 -
32mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
28
J7265144B DRAIN GEAR
TF32-N236R3
29
J7065869A TAKE UP REEL SHAFT
TF32-N240
30
J7065870A
REEL ARM POST TF32-N241
31
J7065872B
COVER TAPE CHUTE TF32-N245R
32
J7265145A
FIXED TAKE UP REEL TF32-N248R
33
J7165275B
PAWL LEVER BLOCK TF32-N255R4
34
J7065867A
STAY BAR
TF32-N139
35
J7065926A
FEEDING SPRING
TF24-N065R2
36
J7065118A
LEVER CENTER SCREW
TF08-033
37
J7065176A
CLAMP LINK
TF12-014R
38
J7065234B RATCHET PAWL TF16-009R
39
J7065929A
PITCH PAWL
TF12-N028
40
J7065323A
HOOK LINK
TF44-039
41
J7065331A
REEL WIND PAWL SPRING
TF44-052R
42
J7065127A
FEEDING SPRING GUIDE
TF44-074
43
J7065340A
RATCHET PAWL SPRING
TF44-075
44
J7065530A
PITCH PAWL SPRING
TF08-020R1
45
J7065347A
ECCENTRIC SHAFT
TF44-091R
46
J7065350A
LEVER SHAFT 1
TF44-107R
47
J7065310A
SPROCKET FIXING SCREW
TF44-024
48
J9065115A MAIN FRAME ASS'Y J9065115A
48-1
J7165271A MAIN FRAME
TF32-N001R2
48-2
J7165274A SPROCKET SHAFT BLOCK
TF32-N141
48-3
J7165103A SPROCKET SHAFT BUSH
TF44-020
48-4
J7165260A PUSHER LEVER BUSH 1
TF12-N072
48-5
J7065151A LOCATION PIN
TF08-075R
48-6
J7065423A
LOCATION PIN TF08-075R1
48-7 J7065158A
PIN SPACER 2 TF08-093
REMARKNO. PART NO. PART NAME TYPE
- E-19 -
32mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
49
J9065106A
SUB FRAME ASS'Y J9065106A
49-1
J7165259A
SUB FRAME
TF24-N002R2
49-2
J7165266A
PUSHER LEVER BUSH 2
TF24-N072
50
J7065935A CHUTE BLADE
TF24-N254
J6107013A TENSION SPRING
AWS5-30
J6107014A CLAMP SPRING
E658
J6071200050
E-RING DIA2 (SUS)
J6071300050
E-RING DIA3 (SUS)
J6071400050
E-RING DIA4 (SUS)
J6071500050
E-RING DIA5 (SUS)
J607020050
E-RING
DIA12 (SUS)
J6073020050
C-RING(SHAFT)
DIA12 (SUS)
J6025300050
HEX NUT
M3 (SUS)
J6025400050
HEX NUT
M4 (SUS)
J6025500050 HEX NUT M5 (SUS)
J6042400050
FLAT WASHER
M4 (SUS)
J6042500050
FLAT WASHER
M5 (SUS)
J6043400050
SPRING WASHER
M4 (SUS)
J6043500050
SPRING WASHER
M5 (SUS)
J6044300050
STAR WASHER
M3 (SUS)
J6006300650
FLAT HEAD CAP SCREW
M3*6 (SUS)
J6006401050
FLAT HEAD CAP SCREW
M4*10 (SUS)
J6004300350
BUTTON HEAD CAP SCREW
M3*3 (SUS)
J6004303250
BUTTON HEAD CAP SCREW
M3*32 (SUS)
J6005402050
BUTTON HEAD CAP SCREW
M4*20 (SUS)
J6007300850
FLAT HEAD SOCKET SCREW
M3*8 (SUS)
J1301161
FLAT HEAD SOCKET SCREW
M2*3 (SUS)
REMARKNO. PART NO. PART NAME TYPE
- E-20 -
