12mm S-Pneumatic Feeder Q'TY 8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm CROSS LEVER ASS'Y (J7000825) 1 J7065202B CROSS LEVER 0 0 1 0 0 0 0 0 0 J7065202B 2 J2500365 PIN 2 0 0 1 0 0 0 0 0 0 TF12-1…

100%1 / 241
12mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
RATCHET PAWL ASS'Y (J7000810)
1 J7065173B
RATCHET PUSHER
0 0 1 0 0 0 0 0 0 J7065173B
2 J2500116
RACHET PUSHER PIN 2
0 0 1 0 0 0 0 0 0
TF12-105
PITCH LINK ASS'Y (J7000811)
1 J7065190B PITCH LINK
0 0 1 1 0 0 0 0 0
J7065190B
2 J2500519 BUSH 1
0 0 1 1 0 0 0 0 0
TF12-121R
MANUAL LEVER ASS'Y (J7000814)
1 J7065329B MANUAL LEVER
0 0 1 1 1 1 1 1 1
J7065329B
2 J2500411 PIN9
0 0 1 1 1 1 1 1 1
TF16-102
3 J2500069 PITCH CAM PIN
0 0 1 1 1 1 1 1 1
TF08-076
CLAMP LEVER 1 ASS'Y (J7000815)
1 J7065168B CLAMP LEVER 1
0 0 1 1 0 0 0 0 0
J7065168B
2 J2500273 CLAMP SPRING PIN 1
0 0 1 1 0 0 0 0 0
TF44-043
3 J2500231 PIN 7
0 0 1 1 0 0 0 0 0
TF12-028R
CLAMP LEVER 2 ASS'Y (J7000817)
1 J2500083 CLAMP LEVER 2
0 0 1 0 0 0 0 0 0
TF12-003
2 J2500231 PIN 7
0 0 1 1 0 0 0 0 0
TF12-028R
SPROCKET LEVER ASS'Y (J7000822)
1 J2500404 SPROCKET LEVER
0 0 1 0 0 0 0 0 0
TF12-007R1
2 J2500298 PIN 1
0 0 1 0 1 0 0 0 0
TF44-112R
3 J2500115 PAWL SPRING PIN 1
0 0 1 0 0 0 0 0 0
TF12-104
4 J2500176 RATCHET LEVER PAWL PIN
0 0 1 1 1 0 0 0 0
TF44-026
REMARKNO. PART NO. PART NAME TYPE
- B-11 -
12mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
CROSS LEVER ASS'Y (J7000825)
1 J7065202B CROSS LEVER
0 0 1 0 0 0 0 0 0
J7065202B
2 J2500365 PIN 2
0 0 1 0 0 0 0 0 0
TF12-123R
3 J2500366 PIN 3
0 0 1 0 0 0 0 0 0
TF12-124R
4 J2500298 PIN 1
0 0 1 0 0 0 0 0 0
TF44-112R
5 J2500384 BUSH 2
0 0 1 0 0 0 0 0 0
TF44-103R
CROSS LEVER LINK ASS'Y (J7000828)
1 J7065175B CROSS LEVER LINK
0 0 1 1 0 0 0 0 0
J7065175B
2 J2500385 BUSH 3
0 0 2 2 0 0 0 0 0
TF12-122R
FEEDING SPRING LEVER ASS'Y (J7000830)
1 J2500357 FEEDING SPRING LEVER
0 0 1 0 0 0 0 0 0
TF12-017R
2 J2500366 PIN 3
0 0 1 0 0 0 0 0 0
TF12-124R
3 J2500367 PIN 8
0 0 1 0 0 0 0 0 0
TF12-125R
4 J2500381 BUSH 8
0 0 1 0 0 0 0 0 0
TF12-127R
LINK 2 ASS'Y (J7000833)
1 J7065174B LINK 2
0 0 1 0 0 0 0 0 0
J7065174B
2 J2500386 BUSH 4
0 0 1 0 0 0 0 0 0
TF44-104R
TAKE UP REEL PLATE ASS'Y (J7000886)
1 J7065460A
TAKE UP REEL PLATE
0 0 1 0 0 0 0 0 0 TF12-047
2 J2500024
SPRING HOOK PIN
0 0 3 0 0 0 0 0 0 TF08-029
3 J2500058
REEL PLATE PIN
0 0 2 0 0 0 0 0 0 TF08-065
4 J2500465
REEL PAWL SHAFT
0 0 1 0 0 0 0 0 0 TF12-044K
5 J2500178
CLAMP SPRING PIN 2
0 0 1 0 0 0 0 0 0 TF44-045
6 J2500172
RELEASE PIN
0 0 1 0 0 0 0 0 0 TF12-094
REMARKNO. PART NO. PART NAME TYPE
- B-12 -
20
38
27
16
10
11
45-1
- 1 -
3
26
1
15
2
5
30
42
33
35
28
13
43
36
41
32
14
40
12
39
29
45-5
45-3
45-4
