16mm N-Pneumatic Feeder Q'TY 12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N TAKE UP REEL PLATE ASS'Y (J9065141A) 1 J7065777A TAKE UP REEL PLATE 1 1 0 0 0 0 0 0 TF12-N201R 2 J7065779A SPRING HOOK PI…
16mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
DRAIN LINK ASS'Y (J9065096A)
1
J7065791A DRAIN LINK 1 1 0 0 0 0 0 0
TF12-N216
2
J7065792A LINK PIN 1 1 0 0 0 0 0 0
TF12-N217
PLANET GEAR ASS'Y (J9065099A)
1
J7265048A PLANET GEAR 3 3 1 1 1 1 1 1
TF08-100K
2
J6601105A ONE WAY BEARING 3 3 1 1 1 1 1 1
HF 0406 KF A
DRAIN WIND LEVER ASS'Y (J9065097A)
1
J7065803A DRAIN WIND LEVER 1 1 0 0 0 0 0 0
TF12-N229
2
J7065789A GEAR SHAFT 2 1 1 0 0 0 0 0 0
TF12-N214
FORMING BRACKET ASS'Y (J9065101A)
1
J7065784B FORMING BRACKET 1 1 0 0 0 0 0 0
TF12-N208R
2
J7065786A FORMING BRACKET BUSH 1 1 0 0 0 0 0 0
TF12-N210
3
J7065823A FORMING SHAFT 1 1 0 0 0 0 0 0
TF16-N239
4
J7065475A SPRING PIN 2 1 1 0 0 0 0 0 0
TF08-Q121
STOPPER ASS'Y (J9065092A)
1
J7065794B
STOPPER OUTTER
1 1 1 1 1 1 1 1 TF12-N219R1
2
J7065800A
STOPPER OUT RATCHET
1 1 1 1 1 1 1 1 TF12-N225
3
J7065798A
STOPPER OUT PIN 1
1 1 1 1 1 1 1 1 TF12-N223
4
J7065793A
STOPPER INNER
1 1 1 1 1 1 1 1 TF12-N218R
5
J7065795B
STOPPER IN PIN 1
2 2 2 2 2 2 2 2 TF12-N220R
6
J7065797A
STOPPER IN BUSH
1 1 1 1 1 1 1 1 TF12-N222
REMARKNO. PART NO. PART NAME TYPE
- C-27 -
16mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
TAKE UP REEL PLATE ASS'Y (J9065141A)
1
J7065777A
TAKE UP REEL PLATE
1 1 0 0 0 0 0 0
TF12-N201R
2
J7065779A
SPRING HOOK PIN
4 4 3 3 3 3 3 3
TF12-N203
3
J7065806A
CLAMP SPRING PIN 2
1 1 1 1 1 1 1 1
TF12-N232
4
J7065192A
REEL PAWL SHAFT
1 1 0 0 0 0 0 0
TF12-044K
5
J7065781A
HINGE SHAFT
1 1 1 1 1 1 1 1
TF12-N205
6
J7065799A
STOPPER OUT PIN 2
1 1 1 1 1 1 1 1
TF12-N224
7
J7065826A
TAPE COVER GUIDE 2
0 2 0 0 0 0 0 0
TF16-N242R
8
J7065790A
TAPE COVER GUIDE PIN
4 4 2 2 2 2 2 2
TF12-N215
9
J7065827A
TAPE ROLLER SHAFT
2 2 0 0 0 0 0 0
TF16-N243
10
J7265134A
TAPE ROLLER 2
2 2 0 0 0 0 0 0
TF12-N244R
11
J7065217A
RELEASE PIN
1 1 1 1 1 1 1 1
TF12-094
12
J7065782A
DRAIN SHAFT-L
1 1 0 0 0 0 0 0
TF12-N206
13
J7065783A
DRAIN SHAFT-S
1 1 0 0 0 0 0 0
TF12-N207
14
J7065801A
DAMPER SHAFT
1 1 1 1 1 1 1 1
TF12-N227
15
J7065474A
SPRING PIN 1
2 2 0 0 0 0 0 0
TF08-Q120
REEL ARM PLATE ASS'Y (J9065091A)
1
J7065778B REEL ARM PLATE 1 1 1 1 1 1 1 1
TF12-N202R2
2
J7065780A BUSH 1 1 1 1 1 1 1 1 1
TF12-N204
3
J7065183A SPRING HOOK PIN 2 2 2 2 2 2 2 2
TF12-022
4
J7065796A STOPPER IN PIN 2 1 1 1 1 1 1 1 1
TF12-N221
5
J7065812B TAPE BRAKE SHAFT 1 1 1 1 1 1 1 1
TF12-N247R
REMARKNO. PART NO. PART NAME TYPE
- C-28 -
