CP,SM Tape Feeder Total CS Manual(V200603).pdf - 第116页
- 3 9 - 1 2 3 4 1 2 3 1 1 2 2 3 2 4 3 1 5 6 7
24mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
J6107013A TENSION SPRING
AWS5-30
J6107014A CLAMP SPRING
E658
J6071200050
E-RING DIA2 (SUS)
J6071300050
E-RING DIA3 (SUS)
J6071400050
E-RING DIA4 (SUS)
J6071500050
E-RING DIA5 (SUS)
J607020050
E-RING
DIA12 (SUS)
J6073020050
C-RING(SHAFT)
DIA12 (SUS)
J6025300050
HEX NUT
M3 (SUS)
J6025400050
HEX NUT
M4 (SUS)
J6025500050 HEX NUT M5 (SUS)
J6042400050
FLAT WASHER
M4 (SUS)
J6042500050
FLAT WASHER
M5 (SUS)
J6043400050
SPRING WASHER
M4 (SUS)
J6043500050
SPRING WASHER
M5 (SUS)
J6044300050
STAR WASHER
M3 (SUS)
J6006300650
FLAT HEAD CAP SCREW
M3*6 (SUS)
J6006401050
FLAT HEAD CAP SCREW
M4*10 (SUS)
J6004300350
BUTTON HEAD CAP SCREW
M3*3 (SUS)
J6004303250
BUTTON HEAD CAP SCREW
M3*32 (SUS)
J6005402050
BUTTON HEAD CAP SCREW
M4*20 (SUS)
J6007300850
FLAT HEAD SOCKET SCREW
M3*8 (SUS)
J1301161
FLAT HEAD CAP SCREW
M2*3 (SUS)
REMARKNO. PART NO. PART NAME TYPE
- D-18 -
- 39 -
1
2
3
4
1
2
3
1
1
2
2
3
2
4
3
1
5
6
7
- 40 -
1
1
2
3
1
2
2
3
1
2
1
2
1
2
3
5
4
