16mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
J9065079A MAIN FRAME ASS'Y 1 1 0 0 0 0 0 0
J9065080A
SPROCKET ASS'Y
1 1 1 0 0 0 0 0
J9065081A
SPROCKET LEVER ASS'Y
1 1 0 0 0 0 0 0
J9065082A
CROSS LEVER ASS'Y
1 1 1 1 1 1 1 1
J9065083A
REWIND LEVER ASS'Y
1 1 1 1 1 1 1 1
J9065084A
LINK 2 ASS'Y
1 1 1 1 1 1 1 1
J9065085A
CLAMP LEVER 1 ASS'Y
1 1 1 1 1 1 1 1
J9065086A
CROSS LEVER LINK ASS'Y
1 1 1 1 1 1 1 1
J9065087A
PITCH LINK ASS'Y
1 1 1 1 1 1 1 1
J9065140A PUSHER LEVER 2 ASS'Y 1 1 0 0 0 0 0 0
J9065089A
CLAMP LEVER 2 ASS'Y
1 1 0 0 0 0 0 0
J9065104A
TAPE GUIDE ASS'Y
0 1 0 0 0 0 0 0
J9065091A
REEL ARM PLATE ASS'Y
1 1 1 1 1 1 1 1
J9065092A
STOPPER ASS'Y
1 1 1 1 1 1 1 1
J9065141A
TAKE UP REEL PLATE ASS'Y
0 1 0 0 0 0 0 0
J9065094A
MANUAL LEVER ASS'Y
1 1 0 0 0 0 0 0
J9065095A
REEL WIND LEVER ASS'Y
1 1 0 0 0 0 0 0
J9065096A
DRAIN LINK ASS'Y
1 1 0 0 0 0 0 0
J9065097A
DRAIN WIND LEVER ASS'Y
1 1 0 0 0 0 0 0
J9065098A
PAWL LEVER ASS'Y
1 1 0 0 0 0 0 0
J9065099A
PLANET GEAR ASS'Y
3 3 1 1 1 1 1 1
J9065100A
PLANET LEVER ASS'Y
1 1 1 1 1 1 1 1
J9065101A
FORMING BRACKET ASS'Y
1 1 0 0 0 0 0 0
J9065102A
FORMING GEAR ASS'Y
1 1 0 0 0 0 0 0
J9065103A
LOCKER ASS'Y
1 1 1 1 1 1 1 1
REMARKNO. PART NO. PART NAME TYPE
- C-15 -
16mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
1
J7265137A VINYL GUIDE ROLLER
TF16-N012
2
J7065817A
VINYL GUIDE ROLLER SHAFT TF16-N011
3
J7065816A
TAPE GUIDE SHAFT TF16-N009
4
J7065818A
LOCKER SHAFT TF16-N014R1
5
J7065822A
LOCKER SPACER TF16-N088
6
J7065824A
TAKE UP REEL SHAFT
TF16-N240
7
J7265138A
FIXED TAKE UP REEL
TF16-N248R
8
J7265071A
REMOVABLE TAKE UP REEL
TF16-076K
9
J7065825A
REEL ARM POST
TF16-N241
10
J7165264A TAPE GUIDE BLOCK TF16-N140R1
11
J7065751A
TAPE SUPPORT
TF12-N016R2
12
J7065752A
TAPE SUPPORT SCREW
TF12-N017
13
J7065763A
FEEDING SPRING BRACKET
TF12-N073R2
14
J7065764A
PITCH CHANGE SCREW
TF12-N077R2
15
J7065769A
ECCENTRIC SHAFT 2
TF12-N101
16
J7065775B
TAPE GUIDE PLATE
TF12-N139R
17
J7065776B
TAPE COVER PLATE
TF12-N140R3
18
J7065937A
TAPE BRAKE
TF16-N209R1
19
J7265131A
DAMPER
TF12-N226R
20
J7065802A
DAMPER WASHER
TF12-N228R
21
J7065804C
REEL GUIDE
TF12-N230R1
22
J7065805A
HOOK LINK
TF12-N231
23
J7265132A
DRAIN GEAR-L
TF12-N235
24
J7065813A
REWIND SPRING
TF12-N252R2
25
J7065814A
DRAIN BRACKET
TF12-N253
26
J7265136B
HANDLE
TF12-N257R3
27
J7065819B
CLAMP LEVER PIN
TF16-N041R
REMARKNO. PART NO. PART NAME TYPE
- C-16 -
16mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
28
J7065756A PUSHER LEVER 1
TF12-N030R
29
J7165286A
PUSHER SUPPORT TF12-N079
30
J7065925A
FEEDING SPRING TF12-N065R1
31
J7065118A
LEVER CENTER SCREW TF08-033
32
J7065088A
IDLER GEAR TF08-Q112
33
J7065176A
CLAMP LINK
TF12-014R
34
J7065198A
SPROCKET SHAFT
TF12-057
35
J7065199A
REEL PAWL SPRING
TF12-061K
36
J7065234B
RATCHET PAWL
TF16-009R
37
J7065929A PITCH PAWL TF12-N028
38
J7065331A
REEL WIND PAWL SPRING
TF44-052R
39
J7065127A
FEEDING SPRING GUIDE
TF44-074
40
J7065340A
RATCHET PAWL SPRING
TF44-075
41
J7065530A
PITCH PAWL SPRING
TF08-020R1
42
J7065347A
ECCENTRIC SHAFT
TF44-091R
43
J7065350A
LEVER SHAFT 1
TF44-107R
44
J7065196A
PUSHER ROLLER
TF12-055R
45
J7065504A
DRAIN PAWL SPRING
TF08-Q153
46
J9065079A
MAIN FRAME ASS'Y
J9065079A
46-1
J7165258A MAIN FRAME
TF12-N001R2
46-2
J7165260A PUSHER LEVER BUSH 1
TF12-N072
46-3
J7065151A LOCATION PIN
TF08-075R
46-4
J7065423A
LOCATION PIN TF08-075R1
46-5 J7065158A
PIN SPACER 2 TF08-093
REMARKNO. PART NO. PART NAME TYPE
- C-17 -
