56mm N-Pneumatic Feeder Q'TY 12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N CLAMP LEVER 1 ASS'Y (J9065085A) 1 J7065760A CLAMP LEVER 1 1 1 1 1 1 1 1 1 TF12-N067 2 J7065325A CLAMP SPRING PIN 1 1 1 1 …
56mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
SPROCKET ASS'Y (J9065129A)
1
J7065753A
SPROCKET
1 1 1 1 1 1 1 1 TF12-N021
2
J7065754A
RATCHET
1 1 1 1 1 1 1 1 TF12-N022R2
3
J7065091A
RATCHET RIVET PIN
3 3 3 3 3 3 3 3 TF08-018
4
J7065363A
SPROCKET SHAFT
0 0 0 0 0 0 0 1 TF56-019
LOCKER ASS'Y (J9065103A)
1
J7065749C LOCKER 1 1 1 1 1 1 1 1
TF12-N013R1
2
J7165263B LOCKER BLOCK 1 1 1 1 1 1 1 1
TF12-N135R
3
J7065772A LOCKER SCREW 3 3 3 3 3 3 3 3 TF12-N136
4
J7065774A LOCKER SPRING 1 1 1 1 1 1 1 1 TF12-N138
5
J7065773A LOCKER SPRING PIN 1 1 1 1 1 1 1 1 TF12-N137
6
J7065942A LOCKER STOPPER 1 1 1 1 1 1 1 1 TF12-N150
7
J7065943A LOCKER STOP SPRING 1 1 1 1 1 1 1 1 TF12-N151
PUSHER LEVER 2 ASS'Y (J9065130A)
1 J7065835A PUSHER LEVER 2
1 1 1 1 1 1 1 1
TF24-N031
2 J7065901A PUSHER LEVER SHAFT
0 0 0 0 0 0 1 1
TF56-N029R
3 J7065902A PUSHER ROLLER SHAFT
0 0 0 0 0 0 1 1
TF56-N032R
PLANET LEVER ASS'Y (J9065100A)
1
J7065228A PLANET LEVER 1 1 1 1 1 1 1 1
TF12-151K
2
J7065788A GEAR SHAFT 1 1 1 1 1 1 1 1 1
TF12-N213
LINK 2 ASS'Y (J9065084A)
1
J7065758A LINK 2 1 1 1 1 1 1 1 1
TF12-N036R
2
J7165262A BUSH 11 1 1 1 1 1 1 1 1
TF12-N134R
3
J7165107A BUSH 4 1 1 1 1 1 1 1 1
TF44-104R
PITCH LINK ASS'Y (J9065087A)
1 J7065757A PITCH LINK
1 1 1 1 1 1 1 1
TF12-N035
2 J7165261A BUSH 10
2 2 2 2 2 2 2 2
TF12-N131R
REMARKNO. PART NO. PART NAME TYPE
- G-23 -
56mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
CLAMP LEVER 1 ASS'Y (J9065085A)
1
J7065760A
CLAMP LEVER 1
1 1 1 1 1 1 1 1 TF12-N067
2
J7065325A
CLAMP SPRING PIN 1
1 1 1 1 1 1 1 1 TF44-043
3
J7065186A
PIN 7
1 1 1 1 1 1 1 1 TF12-028R
CLAMP LEVER 2 ASS'Y (J9065131A)
1 J7065905A CLAMP LEVER 2
0 0 0 0 0 0 0 1
TF56-N068
2 J7065186A PIN 7
1 1 1 1 1 1 1 1
TF12-028R
CROSS LEVER ASS'Y (J9065082A)
1 J7065762B CROSS LEVER
1 1 1 1 1 1 1 1
TF12-N069R
2 J7065351A PIN 6
1 1 1 1 1 1 1 1
TF44-109R
3 J7065771A PIN 11
1 1 1 1 1 1 1 1
TF12-N133
4 J7065770A PIN 12
1 1 1 1 1 1 1 1
TF12-N132
5 J7165106A BUSH 2
1 1 1 1 1 1 1 1
TF44-103R
CROSS LEVER LINK ASS'Y (J9065086A)
1
J7065321B
CROSS LEVER LINK
1 1 1 1 1 1 1 1
TF44-037R2
2
J7165110A
BUSH 7
2 2 2 2 2 2 2 2
TF44-108R
REWIND LEVER ASS'Y (J9065083A)
1 J7065322A REWIND LEVER
1 1 1 1 1 1 1 1
TF44-038
2 J7165106A BUSH 2
1 1 1 1 1 1 1 1
TF44-103R
3 J7065351A PIN 6
1 1 1 1 1 1 1 1
TF44-109R
4 J7065792A LINK PIN
1 1 1 1 1 1 1 1
TF12-N217
SPROCKET LEVER ASS'Y (J9065107A)
1
J7065745A
SPROCKET LEVER
1 1 1 1 1 1 1 1
TF16-030R
2
J7065768A
SHUTER LEVER PIN
1 1 1 1 1 1 1 0
TF16-056 Deletion
3
J7065354A
PIN 1
1 1 1 1 1 1 1 1 TF16-052
4
J7065312A
RATCHET LEVER PAWL PIN
1 1 1 1 1 1 1 1 TF12-121R1
REMARKNO. PART NO. PART NAME TYPE
- G-24 -
56mm N-Pneumatic Feeder
Q'TY
12mm-N 16mm-N 24mm-N 32mmN-S 32mmN-L 44mmN-S 44mmN-L 56mm-N
MANUAL LEVER ASS'Y (J9065112A)
1
J7065845A MANUAL LEVER 0 0 1 1 1 1 1 1
TF24-N233R
2
J7065152A PITCH CAM PIN 1 1 1 1 1 1 1 1
TF12-073
3
J7065792A LINK PIN 1 1 1 1 1 1 1 1
TF12-N217
REEL WIND LEVER ASS'Y (J9065113A)
1
J7065846A REEL WIND LEVER 0 0 1 1 1 1 1 1
TF24-N234R1
2
J7065792A LINK PIN 2 2 1 1 1 1 1 1
TF12-N217
FORMING GEAR ASS'Y (J9065114A)
1
J7265141B FORMING GEAR 0 0 1 1 1 1 1 1
TF24-N238R3
2
J6601125A BEARING 0 0 1 1 1 1 1 1
MR84ZZ
3
J6601105A ONE WAY BEARING 0 0 1 1 1 1 1 1
HF 0406 KF A
PLANET GEAR ASS'Y (J9065099A)
1
J7265048A PLANET GEAR 3 3 1 1 1 1 1 1
TF08-100K
2
J6601105A ONE WAY BEARING 3 3 1 1 1 1 1 1
HF 0406 KF A
STOPPER ASS'Y (J9065092A)
1
J7065794B
STOPPER OUTTER
1 1 1 1 1 1 1 1 TF12-N219R1
2
J7065800A
STOPPER OUT RATCHET
1 1 1 1 1 1 1 1 TF12-N225
3
J7065798A
STOPPER OUT PIN 1
1 1 1 1 1 1 1 1 TF12-N223
4
J7065793A
STOPPER INNER
1 1 1 1 1 1 1 1 TF12-N218R
5
J7065795B
STOPPER IN PIN 1
2 2 2 2 2 2 2 2 TF12-N220R
6
J7065797A
STOPPER IN BUSH
1 1 1 1 1 1 1 1 TF12-N222
REMARKNO. PART NO. PART NAME TYPE
- G-25 -
