CP,SM Tape Feeder Total CS Manual(V200603).pdf - 第36页
3 1 8 7 5 5 6 4 2 1 1 2 2 3 8 9 6 7 1 0 2 5 1 1
1
2
1
2
3
1
2
1
3
2
3
1
3
4
2
3
1
8
7
5
5
6
4
2
1
12
2
3
8
9
6
7
10
2
5
11
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
TAPE GUIDE ASS'Y (J7000774)
1
J2500474 TAPE GUIDE 0 0 0 1 0 0
TF08-002R1
2
J2500405 SHUTTER GUIDE 1 1 1 1 0 0
TF08-008R
3
J2500436 SHUTTER GUIDE PIN 0 0 0 2 0 0
TF08-009N
4
J2500003
TAPE GUIDE ROLLER 1
1 1 1 1 0 0
TF08-005
5 J2500004
TAPE GUIDE ROLLER SHAFT 1
1 1 1 1 0 0
TF08-006
6
J2500435
SHUTTER
0 0 0 1 0 0 TF08-007N
TAPE GUIDE ASS'Y - N(E) (J8100123A)
1
J7065486A TAPE GUIDE 0 0 0 0 1 1
TF08-Q135
2
J7065082A SHUTTER GUIDE 0 0 0 0 1 1
TF08-008R
3
J7065083A SHUTTER GUIDE PIN 0 0 0 0 2 2
TF08-009N
4
J7065405B
TAPE GUIDE ROLLER 1
0 0 0 0 1 1
TF08-005R
5 J7065080A
TAPE GUIDE ROLLER SHAFT 1
0 0 0 0 1 1
TF08-006
6
J7065487A
SHUTTER
0 0 0 0 1 1 TF08-Q136
TAPE GUIDE ASS'Y - 0603P (J9065143A)
1
J7065914A TAPE GUIDE 1 0 0 0 0 0
TF08-251
2
J2500405 SHUTTER GUIDE 1 1 1 1 0 0
TF08-008R
3
J7065916A SHUTTER GUIDE PIN 2 2 2 0 0 0
TF08-253
4
J2500003
TAPE GUIDE ROLLER 1
1 1 1 1 0 0
TF08-005
5 J2500004
TAPE GUIDE ROLLER SHAFT 1
1 1 1 1 0 0
TF08-006
6
J70654915A
SHUTTER
1 0 0 0 0 0 TF08-252
TAPE GUIDE ASS'Y - 1005P, 1005N
1
J7069159A TAPE GUIDE 0 1 1 0 0 0 J7069159A
2
J2500405 SHUTTER GUIDE 1 1 1 1 0 0
TF08-008R
3
J7065916A SHUTTER GUIDE PIN 2 2 2 0 0 0
TF08-253
4
J2500003
TAPE GUIDE ROLLER 1
1 1 1 1 0 0
TF08-005
5 J2500004
TAPE GUIDE ROLLER SHAFT 1
1 1 1 1 0 0
TF08-006
TYPE REMARK
8mm Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 36
