16mm S-Pneumatic Feeder Q'TY 8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm 28 J1301448 FLAT HEAD CAP SCREW M3*6 (SUS) 29 J1301606 BEARING FC-4K (NSK) 30 J2500024 SPRING HOOK PIN TF08-029 31 J2500058 REE…
16mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
1
J7000787 TAPE GUIDE ASS'Y 0 0 0 1 0 0 0 0 0
2
J7000795
SPROCKET ASS'Y
0 0 0 1 0 0 0 0 0
3
J7000801
PUSHER LEVER ASS'Y
0 0 0 1 0 0 0 0 0
4
J7000807
SHUTTER LEVER ASS'Y
0 0 0 1 0 0 0 0 0
5
J7000809
REEL WIND LEVER ASS'Y
0 0 1 1 1 1 1 1 1
6
J7000811
PITCH LINK ASS'Y
0 0 1 1 0 0 0 0 0
7
J7000814
MANUAL LEVER ASS'Y
0 0 1 1 1 1 1 1 1
8
J7000815
CLAMP LEVER 1 ASS'Y
0 0 1 1 0 0 0 0 0
9
J7000818
CLAMP LEVER 2 ASS'Y
0 0 0 1 0 0 0 0 0
10
J7000823 SPROCKET LEVER ASS'Y 0 0 0 1 0 0 0 0 0
11
J7000828
CROSS LEVER LINK ASS'Y
0 0 1 1 0 0 0 0 0
12
J7000831
FEEDING SPRING LEVER ASS'Y
0 0 0 1 0 0 0 0 0
13
J7000887
TAKE UP REEL PLATE ASS'Y
0 0 0 1 0 0 0 0 0
14
J7000826
CROSS LEVER ASS'Y
0 0 0 1 0 0 0 0 0
15
J7000834
LINK 2 ASS'Y
0 0 0 1 0 0 0 0 0
16
J7000891
REEL ARM PLATE ASS'Y
0 0 1 1 1 1 1 1 0
17
18
19
20
21
J1301025
E-RING
DIA12 (SUS)
22
J1301154
FLAT WASHER
M3 (SUS)
23
J1301155
STEEL BALL
DIA4 (NSK)
24
J1301157
FLAT HEAD CAP SCREW
M4*10 (SUS)
25
J1301222
FLAT HEAD CAP SCREW
M3*4 (SUS)
26
J1301308
TENSION SPRING
AWS5-30 (MISUMI)
27
J1301309
CLAMP SPRING
E658 (ULTRA BANE)
REMARKNO. PART NO. PART NAME TYPE
- C-3 -
16mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
28
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
29
J1301606
BEARING
FC-4K (NSK)
30
J2500024
SPRING HOOK PIN
TF08-029
31
J2500058
REEL PLATE PIN
TF08-065
32
J2500118
PUSHER SUPPORT BRACKET
TF16-002
33
J2500121
LOCKER
TF16-013
34
J2500123
REEL ARM POST
TF16-024
35
J2500127
CLAMP LEVER SHAFT
TF16-048
36
J2500133
LOCKER SHAFT
TF16-067
37
J7065247B
TAPE GUIDE SHAFT
J7065247B
38
J2500135
VINYL GUIDE ROLLER
TF16-074
39
J2500136
VINYL GUIDE ROLLER SHAFT
TF16-075
40
J2500138
TAPE COVER
TF16-084
41
J2500140
TAPE COVER PLATE
TF16-092
42
J2500149
SPROCKET SHAFT
TF12-057
43
J2500152
REEL PLATE SPACER
TF12-086
44
J2500158
TAPE BRAKE
TF12-020
45
J2500159
TAPE BRAKE SHAFT
TF12-021
46
J2500160
SPRING HOOK PIN
TF12-022
47
J2500172
RELEASE PIN
TF12-094
48
J2500175
BACKUP GUIDE SCREW
TF44-017
49
J2500178
CLAMP SPRING PIN 2
TF44-045
50
J2500199
BACKUP SPRING
TF44-084
51
J7065234B
RATCHET PAWL
TF16-009R
52
J2500273
CLAMP SPRING PIN 1
TF44-043
53
J2500274
REEL WIND PAWL SPRING
TF44-052R
54
J2500283
RATCHET PAWL SPRING
TF44-075
REMARKNO. PART NO. PART NAME TYPE
- C-4 -
16mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
55
J2500285
STOPPER SPRING
TF44-085
56
J2500370
PUSHER LEVER
TF16-030R
57
J2500372
PUSHER ROLLER
TF16-055R
58
J2500377
TAKE UP REEL SHAFT
TF16-049R
59
J2500380
ECCENTRIC SHAFT 2
TF16-101R2
60
J2500448
PLANET GEAR
TF08-100K
61
J2500461
FIXED TAKE UP REEL
TF16-077K
62
J2500465
REEL PAWL SHAFT
TF12-044K
63
J2500486
STEEL BALL SPRING 2
TF44-080
64
J2500510
REMOVABLE TAKE UP REEL
TF16-076K
65
J2500521
MAIN FRAME
TF16-001R4
66
J7065176B
CLAMP LINK
J7065176B
67
J7065180B
REEL ARM PLATE
J7065180B
68
J7065188B
PUSHER LEVER 2
J7065188B
69
J7065236B
BACKUP GUIDE
TF16-016R1
70
J7065240B
REWIND SPRING
TF12-032R2
71
J7065323B
HOOK LINK
J7065323B
72
73
74
75
76
77
78
79
80
81
REMARKNO. PART NO. PART NAME TYPE
- C-5 -
