0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E) 1 J7000773 SPROCKET ASS'Y 1 1 1 1 1 1 4mm Pitch J8100120A SPROCKET ASS'Y 1 1 1 1 1 1 2mm Pitch 2 J8100123A TAPE GUIDE ASS'Y 1 0 0 0 1 1 3 J7000775 PUSHER LEVER ASS&ap…
49
54
74
70
32
68
22
25
21
48
27
35
27
72
52
55
29
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
1
J7000773 SPROCKET ASS'Y 1 1 1 1 1 1
4mm Pitch
J8100120A SPROCKET ASS'Y 1 1 1 1 1 1
2mm Pitch
2
J8100123A TAPE GUIDE ASS'Y 1 0 0 0 1 1
3
J7000775
PUSHER LEVER ASS'Y
1 1 1 1 1 1
4
J7000776
SHUTTER LEVER ASS'Y
1 1 1 1 1 1
5
J7000777
RACHET PUSHER ASS'Y
1 1 1 1 1 1
6
J7000884
REEL WIND CLANK ASS'Y
1 1 1 1 1 1
7
J7000779
MANUAL LEVER LINK ASS'Y
1 1 1 1 1 1
8
J7000776
REWIND LINK ASS'Y
1 1 1 1 1 1
9
J7000882
TAKE UP REEL PLATE ASS'Y
1 1 1 1 1 1
10
J7165144B
MAIN FRAME
1 1 1 0 1 1
J7165190C
MAIN FRAME
1 1 1 0 1 1 TF08-Q167R4
NST-08E-2P
J7165191C
MAIN FRAME
1 1 1 0 1 1 TF08-Q134E-10
NST-08E-4P
11
J8100125A
CLAMP ARM ASS'Y
1 1 1 0 1 1
RED 2mm Pitch
J8100126A
CLAMP ARM ASS'Y
1 1 1 0 1 1
BLUE 4mm Pitch
12
J8100127A
CLAMP BAR ASS'Y
1 1 1 0 1 1
13
J8100128A
FORMING BRAKET ASS'Y
1 1 1 0 1 1
14
J7000883
DRAIN PAWL ASS'Y
1 1 0 1 1 1
15
J8100124A
SPRING BRAKET ASS`Y
1 0 0 0 0 0
16
J8100133A
POCKET ASS`Y
1 1 1 0 1 1 2mm Pitch
J8100132A
POCKET ASS`Y
1 1 1 0 1 1 4mm Pitch
21
J600630035
FLAT HEAD CAP SCREW
M3*3 (SUS)
22
J604330003
SPRING WASHER
M3
23
J1301023
E-RING
DIA3 (SUS)
24
J1301151
HEX NUT
M6 (SUS)
25
J604230005
FLAT WASHER
M3 (SUS)
TYPE REMARK
0603P-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 3
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
26
J1301155
STEEL BALL DIA4 (NSK)
27
J600640105
FLAT HEAD CAP SCREW
M4*10 (SUS)
28
29
J1301161
FLAT HEAD CAP SCREW
M2*3 (SUS)
30
J7065744A
TAPE SUPPORT
TF08-Q169R2
NST-08E-4P
31
32
J6601027A
BEARING
MR84zz (NSK)
33
J1301266
HEX NUT
M3 (SUS)
34
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
35
J6305001A
UNIVERSAL BUSH
1t, 235L
36
J2500009
STEEL BALL SPRING
TF08-011
37
J7065547A
LOCKER SHAFT
TF08-Q158
38
J2500016
PITCH PAWL
TF08-019R
39
40
J2500028
LEVER CENTER SCREW
TF08-033
41
J2500036
FEEDING SPRING GUIDE
TF08-042R
42
J2500037
FEEDING SPRING BRACKET
TF08-043
43
J2500038
CLAMP LEVER
TF08-044
44
J7065491A
CLAMP SPRING
TF08-Q140
45
J2500040
CLAMP SPRING GUIDE
TF08-046
46
J2500043
MANUAL LEVER
TF08-050
47
J7065482A
REEL LINK
TF08-129
48
J7065434A
REEL ARM PLATE
J7065434A
49
J7065144A REEL ARM POST
TF08-067
50
J2500061 VINYL GUIDE ROLLER
TF08-068R
51
J7265091B VINYL GUIDE ROLLER 2
TF08-Q115R
52
J7065147C
TAPE COVER TF08-070R1
TYPE REMARK
0603P-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
