0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E) FORMING BR AKET ASS'Y - [1005N, N, N(E) (J8100128 A)] 1 J7065481A FORMING BRACKET 0 0 1 0 1 1 TF08-Q128 2 J7065476A FORMING SHAFT 0 0 1 0 1 1 TF08-Q122 3 J7065475A SPRING PIN 2…
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
7 J7065442A
SPRING PIN
1 1
0
1
0 0
J7065442A
8 J7065441B
DRAIN PAWL SHAFT
1 1
0
1
0 0
J7065441B
TAKE UP REEL PLATE ASS'Y - [1005N, N, N(E) (J8100129A)]
1 J7065480B
TAKE UP REEL PLATE 0 0
1
0
1 1 TF08-Q127R
2 J2500024
SPRING HOOK PIN 0 0
1
0
1 1 TF08-029
3 J2500053
TAKE UP REEL SHAFT 0 0
1
0
1 1 TF08-060
4 J7065472A
TAPE GUIDE PIN 1 0 0
1
0
1 1 TF08-Q118
5 J2500058
REEL PLATE PIN 0 0
2
0
2 2 TF08-065
6 J7065468A
HINGE SHAFT 0 0
1
0
1 1 TF08-Q110
7 J7065474A
SPRING PIN 1 0 0
1
0
1 1 TF08-Q120
8 J7065469A
DRAIN SHAFT-L 0 0
1
0
1 1 TF08-Q111
9 J7065470A
DRAIN SHAFT-S 0 0
1
0
1 1 TF08-Q116
10 J7065090B
VINYL GUIDE ROLLER 1 0 0
1
0
1 1 TF08-Q114R
11 J7065471A
VINYL GUIDE PIN 0 0
1
0
1 1 TF08-Q117
12 J7065465A
BUSH 4 0 0
1
0
1 1 TF08-Q107
CLAMP BAR ASS'Y - [1005N, N, N(E) (J8100127A)]
1
J7065494A
CLAMP BAR 0 0
1
0
1 1 TF08-Q143
2
J7065495A
CLAMP BAR TIP 0 0
1
0
1 1 TF08-Q144
3
J7065496A
CLAMP BAR PIN 0 0
1
0
1 1 TF08-Q145
4
J7065498A
CLAMP LINK PIN 0 0
1
0
1 1 TF08-Q147
CLAMP ARM ASS'Y - [1005N, N, N(E) (J8100125A)]
1
J7065493A
CLAMP ARM 0 0
1
0
1 1 TF08-Q142
NST1005(RED)
2
J7065498A
CLAMP LINK PIN 0 0
1
0
1 1 TF08-Q147
CLAMP ARM ASS'Y - [1005N, N, N(E) (J8100126A)]
1
J7065506A
CLAMP ARM 0 0
1
0
1 1 TF08-Q155
NST08(BLUE)
2
J7065498A
CLAMP LINK PIN 0 0
1
0
1 1 TF08-Q147
TYPE REMARK
8mm N(E)-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 40
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
FORMING BRAKET ASS'Y - [1005N, N, N(E) (J8100128A)]
1
J7065481A
FORMING BRACKET 0 0
1
0
1 1 TF08-Q128
2
J7065476A
FORMING SHAFT 0 0
1
0
1 1 TF08-Q122
3
J7065475A
SPRING PIN 2 0 0
1
0
1 1 TF08-Q121
REEL ARM PLATE ASS'Y - [1005N, N, N(E) (J8100130A)]
1 J7065477D
REEL ARM PLATE 0 0
1
0
1 1 TF08-Q123R2
2 J7265093B
HANDLE 0 0
1
0
1 1 TF08-Q131R
J7265099A
HANDLE 0 0
1
0
1 1 TF08-Q168
NST-08E-2P, 4P
3 J7065484A
HANDLE SHAFT 0 0
1
0
1 1 TF08-Q132
4 J7065485A
HANDLE STOPPER 0 0
1
0
1 1 TF08-Q133
POCKET ASS'Y (4mm Pitch) - [1005N, N, N(E) (J8100132A)]
1
J7065478B
POCKET 0 0
1
0
1 1 TF08-Q124R
2
J7065479A
REEL SPACER 0 0
6
0
6 6 TF08-Q125
3 J7065507B
GUIDE PLATE 0 0
1
0
1 1 TF08-Q157R
POCKET ASS'Y (2mm Pitch) - [1005N, N, N(E) (J8100133A)]
1 J7065478B
POCKET 0 0
1
0
1 1 TF08-Q124R
2 J7065479B
REEL SPACER 0 0
6
0
6 6 TF08-Q125R
3 J7065507B
GUIDE PLATE 0 0
1
0
1 1 TF08-Q157R
TYPE REMARK
8mm N-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 41
