0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E) TAPE GUIDE ASS'Y (J7000774) 1 J2500474 TAPE GUIDE 0 0 0 1 0 0 TF08-002R1 2 J2500405 SHUTTER GUIDE 1 1 1 1 0 0 TF08-008R 3 J2500436 SHUTTER GUIDE PIN 0 0 0 2 0 0 TF08-009N 4 J25…
3
1
8
7
5
5
6
4
2
1
12
2
3
8
9
6
7
10
2
5
11
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
TAPE GUIDE ASS'Y (J7000774)
1
J2500474 TAPE GUIDE 0 0 0 1 0 0
TF08-002R1
2
J2500405 SHUTTER GUIDE 1 1 1 1 0 0
TF08-008R
3
J2500436 SHUTTER GUIDE PIN 0 0 0 2 0 0
TF08-009N
4
J2500003
TAPE GUIDE ROLLER 1
1 1 1 1 0 0
TF08-005
5 J2500004
TAPE GUIDE ROLLER SHAFT 1
1 1 1 1 0 0
TF08-006
6
J2500435
SHUTTER
0 0 0 1 0 0 TF08-007N
TAPE GUIDE ASS'Y - N(E) (J8100123A)
1
J7065486A TAPE GUIDE 0 0 0 0 1 1
TF08-Q135
2
J7065082A SHUTTER GUIDE 0 0 0 0 1 1
TF08-008R
3
J7065083A SHUTTER GUIDE PIN 0 0 0 0 2 2
TF08-009N
4
J7065405B
TAPE GUIDE ROLLER 1
0 0 0 0 1 1
TF08-005R
5 J7065080A
TAPE GUIDE ROLLER SHAFT 1
0 0 0 0 1 1
TF08-006
6
J7065487A
SHUTTER
0 0 0 0 1 1 TF08-Q136
TAPE GUIDE ASS'Y - 0603P (J9065143A)
1
J7065914A TAPE GUIDE 1 0 0 0 0 0
TF08-251
2
J2500405 SHUTTER GUIDE 1 1 1 1 0 0
TF08-008R
3
J7065916A SHUTTER GUIDE PIN 2 2 2 0 0 0
TF08-253
4
J2500003
TAPE GUIDE ROLLER 1
1 1 1 1 0 0
TF08-005
5 J2500004
TAPE GUIDE ROLLER SHAFT 1
1 1 1 1 0 0
TF08-006
6
J70654915A
SHUTTER
1 0 0 0 0 0 TF08-252
TAPE GUIDE ASS'Y - 1005P, 1005N
1
J7069159A TAPE GUIDE 0 1 1 0 0 0 J7069159A
2
J2500405 SHUTTER GUIDE 1 1 1 1 0 0
TF08-008R
3
J7065916A SHUTTER GUIDE PIN 2 2 2 0 0 0
TF08-253
4
J2500003
TAPE GUIDE ROLLER 1
1 1 1 1 0 0
TF08-005
5 J2500004
TAPE GUIDE ROLLER SHAFT 1
1 1 1 1 0 0
TF08-006
TYPE REMARK
8mm Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 36
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
6
J70654915A
SHUTTER
1 1 1 0 0 0 TF08-252
SPROCKET ASS'Y
1
J7065410C
SPROCKET
0 0 0 1 1 1 TF08-014R1
J7065564A
SPROCKET
0 0 0 0 1 1 TF08-Q161
NST-08E-2P
J7065917A
SPROCKET
1 1 1 0 1 1 TF08-Q162
NST-08E-4P
J7065566A
SPROCKET
0 0 0 0 1 1 TF08-254
0603P,1005
2
J2500012
RATCHET
0 0 0 1 1 1
J7065918A
RATCHET
1 1 1 0 1 1
3
J7065091A
RATCHET RIVET PIN
0 0 0 2 2 2
J7065921A
RATCHET RIVET PIN
2 2 2 0 2 2
4
J7165139A
SPROCKET SHAFT BUSH
0 0 0 1 1 1
J7065284A
SPROCKET SHAFT BUSH
1 1 1 0 1 1
PUSHER LEVER ASS'Y -[P,N,N(E) (J7000775)], [0603,1005P, 1005N (J7000879)]
1
J7065152B
PITCH CAM PIN 2
2 2 2 2 2 2
TF08-076R
2
J7065123C
PUSHER LEVER
1 1 1 1 1 1
TF08-038R3
3
J2500216
PUSHER ROLLER
1 1 1 1 1 1 TF08-037R
4
J2500217
PUSHER LEVER PIN
1 1 1 1 1 1 TF08-039R1
5
J2500218
PITCH CAM
1 1 1 1 1 1
TF08-040R
6
J2500408
LEVER SHAFT BUSH
1 1 1 1 1 1 TF08-092R1
7
J1300870
FLAT WASHER
1 1 1 1 1 1 M4(SUS)
TYPE REMARK
8mm Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 37
