CP,SM Tape Feeder Total CS Manual(V200603).pdf - 第17页
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E) 1 SPROCKET ASS'Y - 1 1 1 0 0 0 2mm Pitch 2 TAPE GUIDE ASS'Y - 0603 1 0 0 0 0 0 TAPE GUIDE ASS'Y - 1005 0 1 1 0 0 0 3 PUSHER LEVER ASS'Y 1 1 1 0 0 0 4 J7000776 SH…
54
48
21
47
27
52
55
82
76
29
32
68 69
74
70
72
22
25
18
19
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
1
SPROCKET ASS'Y - 1 1 1 0 0 0
2mm Pitch
2
TAPE GUIDE ASS'Y - 0603 1 0 0 0 0 0
TAPE GUIDE ASS'Y - 1005 0 1 1 0 0 0
3
PUSHER LEVER ASS'Y
1 1 1 0 0 0
4
J7000776
SHUTTER LEVER ASS'Y
1 1 1 0 0 0
5
J9065146A
RACHET PUSHER ASS'Y
1 1 1 0 0 0
6
J7000884
REEL WIND CLANK ASS'Y
1 1 1 0 0 0
7
J7000779
MANUAL LEVER LINK ASS'Y
1 1 1 0 0 0
8
J7000776
REWIND LINK ASS'Y
1 1 1 0 0 0
9
J7000882
TAKE UP REEL PLATE ASS'Y
1 1 0 0 0 0
J8100129A
TAKE UP REEL PLATE ASS'Y
0 0 1 0 0 0
10
J7165283C
MAIN FRAME
1 1 1 0 0 0
11
J8100125A
CLAMP ARM ASS'Y
0 1 1 0 0 0 RED
2mm Pitch
CLAMP ARM ASS'Y
1 0 0 0 0 0
RED 2mm Pitch
J8100126A
CLAMP ARM ASS'Y
0 0 0 0 0 0
BLUE 4mm Pitch
12
J8100127A
CLAMP BAR ASS'Y
0 0 1 0 0 0
13
J8100128A
FORMING BRAKET ASS'Y
0 0 1 0 0 0
14
J8100130A
REEL ARM PLATE ASS'Y
0 0 1 0 0 0
J8100131A
REEL ARM PLATE ASS'Y
0 0 1 0 0 0
15
J8100124A
SPRING BRAKET ASS`Y
0 0 1 0 0 0
16
J8100133A
POCKET ASS`Y
0 0 1 0 0 0
2mm Pitch
18
J7265088B
IDLER GEAR
TF08-Q112R
19
J7265089B
DRAIN GEAR-L
TF08-Q113R
20
J1301152
SPRING PIN
PHI2*8 (SUS)
21
J600430035
FLAT HEAD CAP SCREW
M3*3 (SUS)
22
J1300468
SPRING WASHER
M3
TYPE REMARK
1005N-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A -15
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
23
J1301023 E-RING
DIA3 (SUS)
24
J1301151 HEX NUT
M6 (SUS)
25
J1301154 FLAT WASHER
M3 (SUS)
26
J1301155
STEEL BALL DIA4 (NSK)
27
J1301157
FLAT HEAD CAP SCREW M4*10 (SUS)
28
29
J1301161
FLAT HEAD CAP SCREW
M2*3 (SUS)
30
J7065744A
TAPE SUPPORT
TF08-Q169R2
NST-08E-4P
31
32
J1301164
BEARING
MR84zz (NSK)
33
J1301266
HEX NUT
M3 (SUS)
34
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
35
36
J2500009
STEEL BALL SPRING
TF08-011
37
J7065547A
LOCKER SHAFT
TF08-Q158
38
J2500016
PITCH PAWL
TF08-019R
39
40
J2500028
LEVER CENTER SCREW
TF08-033
41
J2500036
FEEDING SPRING GUIDE
TF08-042R
42
J2500037
FEEDING SPRING BRACKET
TF08-043
43
J2500038
CLAMP LEVER
TF08-044
44
J7065491A
CLAMP SPRING
TF08-Q140
45
J2500040
CLAMP SPRING GUIDE
TF08-046
46
J2500043
MANUAL LEVER
TF08-050
47
J7065482A
REEL LINK
TF08-129
48
J7065477D
REEL ARM PLATE
TF08-Q123R2
49
TYPE REMARK
1005N-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 16
