0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E) 26 J1301155 STEEL BALL DIA4 (NSK) 27 J600640105 FLAT HEAD CAP SCREW M4*10 (SUS) 28 29 J1301161 FLAT HEAD CAP SCREW M2*3 (SUS) 30 J7065744A TAPE SUPPORT TF08-Q169R2 NST-08E-4P 31 32 …

100%1 / 241
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
1
SPROCKET ASS'Y - 1005,0603 1 1 1 0 0 0
2mm Pitch
2
TAPE GUIDE ASS'Y - 0603 1 0 0 0 0 0
TAPE GUIDE ASS'Y - 1005 0 1 1 0 0 0
3
PUSHER LEVER ASS'Y
1 1 1 0 0 0
4
J7000776
SHUTTER LEVER ASS'Y
1 1 1 0 0 0
5
J9065146A
RACHET PUSHER ASS'Y
1 1 1 0 0 0
6
J7000884
REEL WIND CLANK ASS'Y
1 1 1 0 0 0
7
J7000779
MANUAL LEVER LINK ASS'Y
1 1 1 0 0 0
8
J7000776
REWIND LINK ASS'Y
1 1 1 0 0 0
9
J7000882
TAKE UP REEL PLATE ASS'Y
1 1 0 0 0 0
J8100129A
TAKE UP REEL PLATE ASS'Y
0 0 1 0 0 0
10
J7165283C
MAIN FRAME
1 1 1 0 0 0
11
J8100125A
CLAMP ARM ASS'Y
0 1 1 0 0 0 RED
2mm Pitch
CLAMP ARM ASS'Y
1 0 0 0 0 0
RED 2mm Pitch
J8100126A
CLAMP ARM ASS'Y
0 0 0 0 0 0
BLUE 4mm Pitch
12
J8100127A
CLAMP BAR ASS'Y
0 0 1 0 0 0
13
J8100128A
FORMING BRAKET ASS'Y
0 0 1 0 0 0
14
J8100130A
REEL ARM PLATE ASS'Y
0 0 1 0 0 0
J8100131A
REEL ARM PLATE ASS'Y
0 0 1 0 0 0
15
J8100124A
SPRING BRAKET ASS`Y
0 0 1 0 0 0
16
J8100133A
POCKET ASS`Y
0 0 1 0 0 0
2mm Pitch
21
J6006300350
FLAT HEAD CAP SCREW
M3*3 (SUS)
22
J6043300036
SPRING WASHER
M3
23
J1301023
E-RING
DIA3 (SUS)
24
J1301151
HEX NUT
M6 (SUS)
25
J6042300050
FLAT WASHER
M3 (SUS)
TYPE REMARK
1005P-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 9
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
26
J1301155 STEEL BALL
DIA4 (NSK)
27
J600640105 FLAT HEAD CAP SCREW
M4*10 (SUS)
28
29
J1301161
FLAT HEAD CAP SCREW M2*3 (SUS)
30
J7065744A
TAPE SUPPORT TF08-Q169R2
NST-08E-4P
31
32
J6601027A
BEARING
MR84zz (NSK)
33
J1301266
HEX NUT
M3 (SUS)
34
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
35
J6305001A
UNIVERSAL BUSH
1t, 235L
36
J2500009
STEEL BALL SPRING
TF08-011
37
J7065547A
LOCKER SHAFT
TF08-Q158
38
J2500016
PITCH PAWL
TF08-019R
39
40
J2500028
LEVER CENTER SCREW
TF08-033
41
J2500036
FEEDING SPRING GUIDE
TF08-042R
42
J2500037
FEEDING SPRING BRACKET
TF08-043
43
J2500038
CLAMP LEVER
TF08-044
44
J7065491A
CLAMP SPRING
TF08-Q140
45
J2500040
CLAMP SPRING GUIDE
TF08-046
46
J2500043
MANUAL LEVER
TF08-050
47
J7065482A
REEL LINK
TF08-129
48
J7065434A
REEL ARM PLATE
J7065434A
49
J7065144A
REEL ARM POST
TF08-067
50
J2500061
VINYL GUIDE ROLLER SHAFT 2
TF08-068R
51
J7265091B
VINYL GUIDE ROLLER 2
TF08-Q115R
52
J7065147C
TAPE COVER
TF08-070R1
TYPE REMARK
1005P-Pneumatic Feeder
NO. PART NO. PART NAME
Q'TY
A - 10
0603P 1005P 1005N 8mm-P 8mm-N 8mm-N(E)
53
J2500064 REWIND LINK SCREW
TF08-071
54
J7065149A TAPE GUIDE PLATE
TF08-073
55
J2500067 REWIND SPRING
TF08-074
56
J2500068
LOCATION PIN TF08-075R
57
J7065153B
PUSHER LEVER GUIDE TF08-077R
58
J2500078
RACHET PUSHER SPRING
TF08-030R
59
J2500457
PITCH PAWL SPRING
TF08-020J
S1005
J2500434
PITCH PAWL SPRING
TF08-020R2
S1608
60
J2500212
STOPPER PIN
TF08-028R1
61
J2500392
ECCENTRIC SHAFT
TF08-021R1
62
63
J2500415
MANUAL LEVER SPRING
TF08-051R2
64
J2500416
PIN SPACER 2
TF08-093
65
66
J2500418
LEVER RETURN SPRING
TF08-041R1
67
J7065488C
LOCKER
TF08-Q137R1
68
J7265078A
FIXED TAKE UP REEL
J7265078A
(Bolt: J1301448)
69
70
J7065432A
DRAIN WIND PAWL SPRING
J7065432A
71
J2500407
LEVER CENTER SCREW
TF08-033R2
72
J7265086A
FORMING GEAR 1
TF08-P119
J7265087A
FORMING GEAR 2
TF08-P120
73
J2500525
PLANET SPRING
TF08-104KA
74
J7265076B
PLANET LEVER
TF08-102KA
75
J7065423A
LOCATION PIN
J7065423A
76
77
J7065499A
LOCKER SPRING
TF08-Q148
