44mm S-Pneumatic Feeder Q'TY 8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm 82 J7065323B HOOK LINK J7065323B 83 J7065338B FEEDING SPRING BRACKET J7065338B 84 J7065348B ECCENTRIC SHAFT 2 TF44-101R2 85 86 …
44mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
55
J2500285
STOPPER SPRING
TF44-085
56
J2500286
ECCENTRIC SHAFT
TF44-091R
57
J2500288
SPRING PROTECTOR
TF44-102R
58
J2500293
LEVER SHAFT 1
TF44-107R
59
J2500322
SPROCKET FIXING SCREW
TF44-024
60
J2500327
VINYL GUIDE ROLLER SHAFT
TF44-011
61
J2500328
VINYL GUIDE ROLLER
TF44-012
62
J2500329
LOCKER
TF44-013R
63
J2500330
LOCKER SHAFT
TF44-014
64
J2500337
PUSHER ROLLER
TF44-033R
65
J2500338
TAKE UP REEL SHAFT
TF44-048R
66
J2500339
REEL ARM POST
TF44-066
67
J2500343
PUSHER SUPPORT PLATE
TF44-079
68
J2500344
LOCKER SPACER
TF44-088
69
J2500409
PITCH CHANGE SCREW
TF44-077R1
70
J2500413
CLAMP LEVER PIN
TF44-041
71
J2500448
PLANET GEAR
TF08-100K
72
J2500464
FIXED TAKE UP REEL
TF44-077K
73
J2500465
REEL PAWL SHAFT
TF12-044K
74
J2500523
STEEL BALL SPRING 3
TF44-081
75
J2500487
MAIN FRAME
TF44-005R1
76
J2500513
REMOVABLE TAKE UP REEL
TF44-076K
77
J7065176B
CLAMP LINK
J7065176B
78
J7065180B
REEL ARM PLATE
J7065180B
79
J7065281B
REWIND SPRING
TF24-089R3
80
J7065301B
TAPE GUIDE SHAFT
J7065301B
81
J7065305B
BACKUP GUIDE
TF44-016R2
REMARKNO. PART NO. PART NAME TYPE
- F-5 -
44mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
82
J7065323B
HOOK LINK
J7065323B
83
J7065338B
FEEDING SPRING BRACKET
J7065338B
84
J7065348B
ECCENTRIC SHAFT 2
TF44-101R2
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
REMARKNO. PART NO. PART NAME TYPE
- F-6 -
2
1
2
1
3
4
1
6
2
3
4
5
7
1
6
2
3
4
5
7
