32mm S-Pneumatic Feeder Q'TY 8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm 28 J1301309 CLAMP SPRING E658 (ULTRA 29 J1301448 FLAT HEAD CAP SCREW M3*6 (SUS) 30 J1301606 BEARING FC-4K (NSK) 31 J2500009 STE…
32mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
1
J7000885
SHUTTER LEVER ASS'Y
0 0 0 0 1 1 1 1 0
2
J7000386 SPROCKET 2 ASS'Y 0 0 0 0 0 1 1 1 1
3
J7000789 TAPE GUIDE ASS'Y 0 0 0 0 0 1 0 0 0
4
J7000797 SPROCKET ASS'Y 0 0 0 0 0 1 0 0 0
5
J7000803
PUSHER LEVER ASS'Y
0 0 0 0 0 1 0 0 0
6
J7000809
REEL WIND LEVER ASS'Y
0 0 1 1 1 1 1 1 1
7
J7000813
PITCH LINK ASS'Y
0 0 0 0 0 1 1 1 1
8
J7000814
MANUAL LEVER ASS'Y
0 0 1 1 1 1 1 1 1
9
J7000816
CLAMP LEVER 1 ASS'Y
0 0 0 0 1 1 1 1 1
10
J7000820
CLAMP LEVER 2 ASS'Y
0 0 0 0 0 1 0 0 0
11
J7000824 SPROCKET LEVER ASS'Y 0 0 0 0 1 1 1 1 0
12
J7000827
CROSS LEVER ASS'Y
0 0 0 0 1 1 1 1 1
13
J7000829
CROSS LEVER LINK ASS'Y
0 0 0 0 1 1 1 1 1
14
J7000832
REWIND LEVER ASS'Y
0 0 0 0 1 1 1 1 1
15
J7000835
LINK 2 ASS'Y
0 0 0 0 1 1 1 1 1
16
J7000888
TAKE UP REEL PLATE ASS'Y
0 0 0 0 1 1 1 1 0
17
J7000891
REEL ARM PLATE ASS'Y
0 0 1 1 1 1 1 1 0
18
19
20
21
J1301025
E-RING
DIA12 (SUS)
22
J1301154
FLAT WASHER
M3 (SUS)
23
J1301155
STEEL BALL
DIA4 (NSK)
24
J1301157
FLAT HEAD CAP SCREW
M4*10 (SUS)
25
J1301222
FLAT HEAD CAP SCREW
M3*4 (SUS)
26
J1301226
C-RING (SHAFT)
DIA12 (SUS)
27
J1301308
TENSION SPRING
AWS5-30
REMARKNO. PART NO. PART NAME TYPE
- E-3 -
32mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
28
J1301309
CLAMP SPRING
E658 (ULTRA
29
J1301448
FLAT HEAD CAP SCREW
M3*6 (SUS)
30
J1301606
BEARING
FC-4K (NSK)
31
J2500009
STEEL BALL SPRING
TF08-011
32
J2500024
SPRING HOOK PIN
TF08-029
33
J2500058
REEL PLATE PIN
TF08-065
34
J2500158
TAPE BRAKE
TF12-020
35
J2500159
TAPE BRAKE SHAFT
TF12-021
36
J2500160
SPRING HOOK PIN
TF12-022
37
J2500172
RELEASE PIN
TF12-094
38
J2500175
BACKUP GUIDE SCREW
TF44-017
39
J2500178
CLAMP SPRING PIN 2
TF44-045
40
J2500199
BACKUP SPRING
TF44-084
41
J2500268
PUSHER LEVER 2
TF44-031
42
J2500273
CLAMP SPRING PIN 1
TF44-043
43
J2500274
REEL WIND PAWL SPRING
TF44-052R
44
J2500280
TAPE COVER PLATE
TF44-067
45
J2500283
RATCHET PAWL SPRING
TF44-075
46
J2500301
TAPE GUIDE SHAFT
TF32-009
47
J2500302
VINYL GUIDE ROLLER SHAFT
TF32-011
48
J2500303
VINYL GUIDE ROLLER
TF32-012
49
J2500304
LOCKER
TF32-013R
50
J2500305
LOCKER SHAFT
TF32-014
51
J2500311
PUSHER ROLLER
TF32-033R1
52
J2500312
CLAMP LEVER PIN
TF32-041
53
J2500313
TAKE UP REEL SHAFT
TF32-049R
54
J2500314
REEL ARM POST
TF32-066
REMARKNO. PART NO. PART NAME TYPE
- E-4 -
32mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
55
J2500318
PUSHER SUPPORT PLATE
TF32-079R2
56
J2500320
LOCKER SPACER
TF32-088
57
J2500322
SPROCKET FIXING SCREW
TF44-024
58
J2500448
PLANET GEAR
TF08-100K
59
J2500463
FIXED TAKE UP REEL
TF32-077K
60
J2500465
REEL PAWL SHAFT
TF12-044K
61
J2500484
MAIN FRAME
TF32-005R2
62
J2500512
REMOVABLE TAKE UP REEL
TF32-076K
63
J7065176B
CLAMP LINK
J7065176B
64
J7065180B
REEL ARM PLATE
J7065180B
65
J7065234B
RATCHET PAWL
TF16-009R
66
J7065281B
REWIND SPRING
TF24-089R3
67
J7065287B
BACKUP GUIDE
TF32-016R2
68
J7065323B
HOOK LINK
J7065323B
69
70
71
72
73
74
75
76
77
78
79
80
81
REMARKNO. PART NO. PART NAME TYPE
- E-5 -
