CP,SM Tape Feeder Total CS Manual(V200603).pdf - 第132页
1 3 2 3 1 2 6 4 5
1
4
3
2
2
1
1
3
2
1
2
1
3
2
3
1
2
6
4
5
32mm S-Pneumatic Feeder
Q'TY
8mm-S 8mm-P 12mm-S 16mm-S 24mm-S 32mm-S 44mm-S 44mm-L 56mm
TAPE GUIDE ASS'Y (J7000789)
1
J2500485 TAPE GUIDE 0 0 0 0 0 1 0 0 0
TF32-008R2
2 J2500262
SHUTTER GUIDE PLATE 0 0 0 0 0 1 0 0 0
TF24-087
3 J2500261
SHUTTER RIVET PIN 0 0 0 0 0 2 0 0 0
TF24-086R
4 J2500303
VINYL GUIDE ROLLER
0 0 0 0 0 1 0 0 0
TF32-012
5 J2500302
VINYL GUIDE ROLLER SHAFT
0 0 0 0 0 1 0 0 0
TF32-011
6 J2500319
SHUTTER
0 0 0 0 0 1 0 0 0
TF32-085R
7
J1301160
E-RING
0 0 2 2 2 2 0 0 0 DIA 2(SUS)
SPROCKETE ASS'Y (J7000797)
1 J7065308B
SPROCKET
0 0 0 1 1 1 0 0 0 J7065308B
2 J2500195
RATCHET
0 0 0 1 1 1 0 0 0 TF44-022
3 J2500015
RATCHET RIVET PIN
1 1 1 1 1 2 0 0 0 TF08-018
4 J2500307
SPROCKET SHAFT
0 0 0 0 0 1 0 0 0 TF32-019R
SPROCKETE 2 ASS'Y (J7000386)
1 J7065308B SPROCKET
0 0 0 0 0 1 1 1 1
J7065308B
2 J2500321 SPROCKET BUSH
0 0 0 0 0 1 1 1 1 TF44-023
PUSHER LEVER ASS'Y (J7000803)
1 J7065315B
PUSHER LEVER 1
0 0 0 0 0 1 0 0 0
J7065315B
2
J2500310
PUSHER ROLLER SHAFT
0 0 0 0 0 1 0 0 0
TF32-032
3
J2500421
PUSHER LEVER SHAFT
0 0 0 0 0 1 0 0 0 TF32-029R
PITCH LINK ASS'Y (J7000813)
1 J2500323 PITCH LINK
0 0 0 0 0 1 1 1 1
TF44-035R
2 J2500388 BUSH 6
0 0 0 0 0 2 2 2 2
TF44-016R
REMARKNO. PART NO. PART NAME TYPE
- E-10 -
