1 Introduction Instruction manual SIPLACE TX
1.1 Important notes on the instruction manual From software version 714.0 12/2020
18
1.1.5.2 SIPLACE on the World Wide Web (WWW)
We also have our own site on the Internet. Why not log into our homepage at http://www.asm-smt-
solutions.com.
All the menus and other information are available in two languages: You can choose between the
German and English versions.
The various headings contain information on
– Our products
– Services
– Contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– Technical documentation
– Technical information
– Spare parts catalogs etc.
Registering for access to the User Group is easy:
Click on ’Register now’.
Complete the registration form and just send it off.
You will then quickly receive access authorization with USER ID and a password.
1.1.6 Abbreviations
1
A-Placement Alternating Placement
PA Placement area
CO Component
C&P20 P2 High-performance Collect&Place head with 20 segments, SIPLACE SpeedStar
C&P20 M3 High-resolution Collect&Place head with 20 segments, SIPLACE SpeedStar
CPP Collect&Place head, SIPLACE MultiStar
DCA Direct chip attach
DC Dual conveyor
EDIF Energy and data interface
ESD Electrostatically-sensitive group of components
EMC Electromagnetic compatibility
ESD Electrostatic sensitive device
FC Flip chip
Instruction manual SIPLACE TX 1 Introduction
From software version 714.0 12/2020 1.1 Important notes on the instruction manual
19
WT Waffle pack tray
WTC Waffle pack tray carrier
MGCU Modular Gantry Control Unit
GND Ground
MHCU Modular Head Control Unit
I-Placement Independent placement
JTF-ML JEDEC Tray Feeder
PCB Printed circuit board
MCS Machine capability study
P&P Pick&Place
P&P1 Pick&Place module 1
P&P2 Pick&Place module 2
NC Nozzle changer
SMD Surface mounted device
SC Station computer
TH Twin Pick&Place head, SIPLACE TwinStar
VS Vision system
1 Introduction Instruction manual SIPLACE TX
1.2 Overview From software version 714.0 12/2020
20
1.2 Overview
1.2.1 SIPLACE TX1/TX2
1
Fig. 1.2 - 1 SIPLACE TX1/2 placement machine
(T) Direction of travel
(1) Location 1 - outer
(2) Location 2 - inner
(1)
(2)
