Instruction manual SIPLACE TX 1 Introduction
From software version 714.0 12/2020 1.3 SIPLACE TX
23
1.3.2 Placement Head Configurations
1
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
Placement
machine
Placement head Standard cameras Options
SIPLACE
TX1
C&P20 P2 Component camera, type 48 --
CPP_H
Component camera, type 30 Component camera, type 45
Stationary camera, type 33 (only at
location 1)
TH Stationary camera, type 33
(only at location 1)
Stationary camera, type 25 (only at
location 1)
SIPLACE
TX2
C&P20 P2 / C&P20 P2 Component camera, type 48 --
C&P20 P2 / CPP_L
Component camera, type 48
Component camera, type 30
--
Component camera, type 45
CPP_L/CPP_L Component camera, type 30 Component camera, type 45
CPP_H / CPP_H
Component camera, type 30 Component camera, type 45
Stationary camera, type 33 (only at
location 1)
TH / CPP_H
Stationary camera, type 33
(only at location 1)
Stationary camera, type 25 (only at
location 1)
Component camera, type 30 Component camera, type 45
SIPLACE
TX2i
C&P20 P2 / C&P20 P2 Component camera, type 48 --
CPP_L/CPP_L Component camera, type 30 Component camera, type 45
1 Introduction Instruction manual SIPLACE TX
1.4 SIPLACE TX m From software version 714.0 12/2020
24
1.4 SIPLACE TX m
1.4.1 Description
In addition to the features of the SIPLACE TX, the SIPLACE TX m placement machines also
demonstrate top placement quality for advanced packaging, high-volume production.
The SIPLACE TX2 m supports the accuracy class for enhanced placement accuracy of
15 µm
(3σ) and 20 µm (3σ).
The SIPLACE TX2i m also offers the entire benchmark placement performance range of
96,000
[components/h] at an accuracy of 25 µm (3σ) and 85,500 [components/h] with the
SIPLACE TX2 m.
The SIPLACE TX2i m 4 mm facilitates placement of 4 mm high components with the C&P20 M3
placement head.
1
1
Type Description
SIPLACE TX2 m – Placement machine with two gantries
– Table position "outside" at location 1
– Table position "inside" at location 2 with short cover
– Very high accuracy
SIPLACE TX2i m – Placement machine with two gantries
– Table position "innermost position" at location 1 and 2
– Short covers at location 1 and 2 for optimum ease of use
– Narrow nozzle changer with 3 magazines
– Very high accuracy
SIPLACE TX2i m 4 mm – Placement machine with two gantries
– Table position "innermost position" at location 1 and 2
– Short covers at location 1 and 2 for optimum ease of use
– Narrow nozzle changer with 3 magazines
– Very high accuracy
– Placement of 4 mm high components with C&P20 M3.
PLEASE NOTE
Table position "innermost position" for SIPLACE TX2i m
The table positions for the SIPLACE TX2i m have been moved even further inwards than
the position "inner" used for the SIPLACE TX2 m .
Instruction manual SIPLACE TX 1 Introduction
From software version 714.0 12/2020 1.4 SIPLACE TX m
25
Very high accuracy 1
To achieve maximum accuracy, the SIPLACE TX m placement machines are equipped with high
resolution glass ceramic scales on the main axes and the C&P20 M3 or CPP M heads. A highly
rigid PCB conveyor and an additional fiducial rail are also used.
1.4.2 Placement Head Configurations
1
Placement
machine
Placement head Standard cameras Options
SIPLACE
TX2i m
C&P20 M3 / C&P20 M3 – Component camera,
type 48
– Component camera, type 49
SIPLACE
TX2i m 4 mm
C&P20 M3 / C&P20 M3 – Component camera,
type 48
– Component camera, type 49
SIPLACE
TX2 m
C&P20 M3 / C&P20 M3 – Component camera,
type 48
– Component camera, type 49
CPP M/CPP M – Component camera,
type 45
– Component camera, type 30
C&P20 M3 / CPP M – Component camera,
type 48
– Component camera,
type 45
– Component camera, type 49
– Component camera, type 30
