1 Introduction Instruction manual SIPLACE TX 1.7 Operator levels From software version 714.0 12/2020 34
Instruction manual SIPLACE TX 1 Introduction
From software version 714.0 12/2020 1.7 Operator levels
33
1.7 Operator levels
Certain functions or menus may only be executed or accessed by specially trained personnel. A
differentiation is made between the following operator levels:
– Production
– Advanced production
– Service (customer)
The operator levels "Advanced production" and "Service (customer)" can be password protected.
Production 1
This operator level includes those people who have been trained to operate the placement ma-
chine. These people are authorized to use any functions associated with operating the placement
machine and may call up any menus needed to use the machine.
Advanced production 1
People with this operator level have completed special training and are authorized to perform
setup tasks e.g. creating setup configurations or determining Vision parameters etc.
Service (customer) 1
People with this operator level are specially trained technicians at the customer end, who can, for
example, define placement machine option settings.
1
1 Introduction Instruction manual SIPLACE TX
1.7 Operator levels From software version 714.0 12/2020
34
Instruction manual SIPLACE TX 2 Operational safety
From software version 714.0 12/2020 2.1 Safety instructions
35
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This manual contains notes that must be observed to guarantee your personal safety and to avoid
damage to equipment. These notes are highlighted by warning triangles and are indicated as fol-
lows according to the level of risk:
2
2
2
2
DANGER
Definition
Danger, as used in this manual, means that death, severe injury or considerable damage
to equipment will occur if the danger instructions are not followed.
WARNING
Definition
Warning, as used in this manual, means that death, severe injury or considerable dam-
age to equipment may occur if the warning instructions are not followed.
CAUTION
Definition
Caution, as used in this manual, means that slight injury or damage to equipment may
occur if the caution instructions are not followed.
PLEASE NOTE
Definition
A note, as used in this manual, provides information on the product or indicates a part of
the manual that requires particular attention.
