5.13 Avoiding track errors
5.13.1 General
Make sure that the areas around the feeder modules are clean and that there are no loose
components in the feeder area or under the feeder modules.
Refill promptly with components.
With tape feeder modules, make sure that you always splice on a new tape early enough so
that the feeder modules do not run out of components.
However, do not splice the tapes too early because if you wind the tape onto the new reel
after splicing the end of the old tape, the reel with the new tape may be overfilled. The tape
could then slip off the reel and become tangled. Under certain circumstances, this could
cause pick-up errors and prolonged down times.
5
Splice the tapes early. This generally means that you are to prepare the splicing material
when there is still approximately 1.5 m of tape on the reel.
Handle the feeder modules carefully when you insert them into or remove them from the
changeover table as these are high-precision devices.
For X feeder modules, lower the pickup window since it can easily be damaged when raised.
5
Check that the pick-up position is set correctly for the components on the feeder modules.
Check whether the separating plates have been correctly inserted.
PLEASE NOTE
The online help contains information on refilling components with and without barcodes.
PLEASE NOTE
A raised pick-up window leads to noticeably impaired pick-up quality.
5 Tasks at the placement machine Instruction manual SIPLACE TX
5.13 Avoiding track errors From software version 714.0 12/2020
264
5.13.2 Component coordinate system and pickup angle
5
Fig. 5.13 - 1 Position of the component and its pick-up angle
Special
component
Stick
magazine:
Chip-
components
with polarity
0402
2220
The anode must be
aligned with the +X
coordinate.
Package form
type
0° coordinate system
Position in the feeder module
Pickup angle/
nozzle angle
Tape:
SOT 23
Stick
magazine:
Tape:
Tape:
SO-IC
DIL-IC
SOT 194
Tape:
Holes
Y
X
Y
X
Y
X
Y
X
Y
X
90°
90°
0°
90°
-90°
0°
Instruction manual SIPLACE TX 5 Tasks at the placement machine
From software version 714.0 12/2020 5.14 Docking the component trolley in or out
265
5.14 Docking the component trolley in or out
5.14.1 Safety instructions for docking component trolleys in and out
Also follow the safety instructions given in section 2.4.10, page 79.
5
5
There is a button at each location (1 and 2). The safety concept for the component trolley change-
over specifies that the operator should push this button at the relevant placement machine loca-
tion, to dock or undock the component trolley.
WARNING
DANGER OF CRUSHING!
Risk of crushing when docking and undocking the component trolley.
Always dock/undock the component trolley alone.
When docking and undocking, make sure that there are no body limbs in the travel
area of the component trolley.
PLEASE NOTE
Docking only possible if protective cover is closed
Close the protective covers.
