User Manual SIPLACE D3 5 Tasks for the operating personnel
From software version SR.605.xx 07/2008 EN Edition 5.10 Docking the component trolley in or out
277
5.10 Docking the component trolley in or out
5.10.1 Safety instructions for docking the component trolley in or out
WARNING
To prevent accidents (risk of crushing), the component trolley may only be docked in or out by
one person.
5
Fig. 5.10 - 1 Button for docking component trolleys in and out
(1) Button for docking the component trolley in or out, location 1
(2) Button for docking the component trolley in or out, location 2
(3) Button for docking the component trolley in or out, location 3
(4) Button for docking the component trolley in or out, location 4
(T) Direction of PCB transport
5 Tasks for the operating personnel User Manual SIPLACE D3
5.10 Docking the component trolley in or out From software version SR.605.xx 07/2008 EN Edition
278
The safety concept for the component trolley change requires the operator to press a button (item
1, 2, 3 or 4 in Fig. 5.10 - 1
, page 277) on the input or output side of the machine in order to dock
the component trolley in or out. This ensures that the operator is always standing to the side of
the machine. In addition, the component trolley can only be docked in if the protective covers are
closed.
5.10.2 Docking out the component trolley
→ Press one of the buttons on the input or output side of the machine (item 1, 2, 3 or 4 in Fig.
5.10 - 1
, page 277) until the CO trolley is docked out fully.
→ Swivel the two handles up (item 1 in Fig. 5.10 - 2
).
5
Fig. 5.10 - 2 Component trolley - swivel handles up to push
5
→ With both hands on the handles, pull the component trolley out of the machine.
5.10.3 Safety instructions for moving the component trolley
WARNING
To prevent accidents, ALWAYS follow the rules listed below when you move the component trol-
ley.
User Manual SIPLACE D3 5 Tasks for the operating personnel
From software version SR.605.xx 07/2008 EN Edition 5.10 Docking the component trolley in or out
279
→ Always hold the handles with both hands when you want to move the component trolley.
→ Remember that a component trolley with the full complement of feeder modules can tip over
sideways or forward on gradients of 20° or more.
→ Make sure that the surface on which the trolley is moved has a significantly smaller gradient.
→ Be careful not to collide with obstacles. The trolley could tip forward if it is traveling fast
enough.
5.10.4 Docking in the component trolley
PLEASE NOTE
Shorten the component tapes on the front end of the S feeder modules to approximately 1 cm
before you dock in the component trolley.
CAUTION
Check that the placement head is outside the range of the component trolley.
→ Carefully push the component trolley into machine as far as the stop.
PLEASE NOTE
Close the protective covers since the component trolley can only be docked in if the covers are
closed.
→ Press the relevant button on the input or output side of the machine (item 1, 2, 3 or 4 in Fig.
5.10 - 1
, page 277), until the trolley is docked in fully.
→ Push the sleeve (item 1 in Fig. 5.10 - 3
, page 280) up using both handles and swivel the han-
dle down (item 2 in Fig. 5.10 - 3
, page 280).
