Assembly instructions Feeder cover flap, SIPLACE HF-series / X-series / D3 05/2009 Edition 44 2.4 Safety instructions W ARNIN G The safety instructio ns from the “Operational safety” chapte r of the user manual and servi…
Assembly instructions Feeder cover flap, SIPLACE HF-series / X-series / D3
05/2009 Edition
43
2.3.1 Assembly kits
2
If there still the old empty tape duct with FS -03 is mounted, you need additionally: 2
2
2
2
2 Quantity 2 Name 2 Item number 2
2 1 2 Feeder Cover HF Sec. 1/3 compl.: 00119933-xx 2 03065933-xx 2
2 1 2 Feeder Cover HF Sec. 1/3 2 03065992-xx 2
2 1 2 Flap Switch X-series 2 03056172-xx 2
2 1 2 Feeder Cover HF Sec. 2/4 compl.: 00119910-xx 2 03065932-xx 2
2 1 2 Feeder Cover HF Sec. 2/4 2 03065999-xx 2
2 1 2 Flap Switch X-series 2 03056172-xx 2
2 1 2 Empty tape duct 2 03021990-04 or higher 2
Assembly instructions Feeder cover flap, SIPLACE HF-series / X-series / D3
05/2009 Edition
44
2.4 Safety instructions
WARNING
The safety instructions from the “Operational safety” chapter of the user manual and servicing in-
structions take precedence over these instructions. 2
The SIPLACE placement machines are supplied with main power voltage.
Consequently parts of these systems carry dangerous voltages! This voltage is present at certain
modules inside the machine base, even when the machine is switched off at the main power
switch.
Incorrect handling of the placement machine or touching live parts of the machine can result in
death or severe injury, and considerable damage to equipment.
BEFORE starting any work, shut down the operating system correctly, then switch the machine
OFF at the main power switch and disconnect from the main power supply. In addition, the com-
pressed air supply must be switched off at the compressed air unit's main valve in the machine
base and vented by actuating the needle valve on the compressed air unit.
There is DANGER for heart pacemaker wearers in the vicinity of the linear motors, as described
in detail in the "Special safety instructions for working in the vicinity of strong magnetic fields"
section of the user manual and service manual.
Always follow the accident prevention regulations, DIN or other standards and special safety
rules applicable in your country.
Pay attention to the information concerning residual voltages in the Operational Safety chapter.
Follow the ESD regulations as described in the operational safety section of the operating
instructions.
During the retrofit, always secure the machine to prevent access by other people and to prevent
it being switched on again as described in the "Lock out and tag out procedure" in the user man-
ual.
Working with the SITEST program further increases the risk of accident.
The SITEST program must only be used by authorized and trained personnel.
2
2
2.4.1 Definitions
2
Please note 2
2
2
2
Caution 2
Assembly instructions Feeder cover flap, SIPLACE HF-series / X-series / D3
05/2009 Edition
45
2.4.2 Special safety instructions
2
ATTENTION 2
Before starting the retrofit, all safety instructions from the according Service Manuals must be
read.
Special attention has to be taken on the chapter Safety Instructions for Work on the Cutting De-
vice. 2
There is a high risk of injury due to wrong handling of the cutting unit. 2
If any covers or sheets must be removed, take care of the grounding contactors that may be at-
tached. It’s easy to tear them of. 2
If it is necessary to remove the grounding contactors, make sure that they will be connected cor-
rectly again during assembly. 2
2.4.3 Preliminaries
– Most screws have to be used again to assemble the new parts.
– Keep all screws because you will some of them again for assembly.
– The real condition of the machine may sometimes differ from the pictures or can be used mir-
ror-inverted on the other location.
– The following assembly instruction describes the installation of the protective plate at location
2 on a HF/3-machine.
– The wiring for the switches is almost the same for every location.
