3 Technical data and assemblies User manual SIPLACE TX V2 3.8 SIPLACE tape feeder modules for SIPLACE TX From software version 711.1 04/2018 138 3.8.1.3 Design of the SIPLACE SmartFeeder X The following diagram shows the…
User manual SIPLACE TX V2 3 Technical data and assemblies
From software version 711.1 04/2018 3.8 SIPLACE tape feeder modules for SIPLACE TX
137
3.8 SIPLACE tape feeder modules for SIPLACE TX
The SIPLACE TX uses the SIPLACE SmartFeeder X and the SIPLACE SmartFeeder Xi. The
specified SIPLACE tape feeder modules are compatible with the SIPLACE TX changeover tables.
Key features of the SIPLACE tape feeder modules include high pickup position precision, online
programming and simple handling of feeder module changeovers during the placement process.
The power supply to the feeder modules is contactless and uses an inductive interface. Each
feeder module communicates with the feeder module control unit (FCU) via two optoelectronic
channels (optical fiber). The two interfaces form the EDIF assembly (energy and data interface).
3.8.1 SIPLACE tape feeder module
3.8.1.1 Tape material
The tape width spectrum for SIPLACE TX ranges from 4 mm to 56 mm. The tape material is blister
or paper. Component tapes with a permanently adhesive cover foil (PSA foil) can also be pro-
cessed as a default.
The design of the tape feeder modules was based on the following tape standards:
DIN EN 60286-3 (12/1998) / IEC 60286-3 (12/1997)
JIS C 0806-3 (1999)
ANSI/EIA 481-C (10/2003)
IEC 60286-3-2 3
3.8.1.2 Manual removal of tantalum capacitors which were not picked up
To prevent tantalum capacitors which were not picked up from causing the tape material to burn
when it is cut, the user interface has been extended to include the option "Stop immediately on
pickup error". This option must be enabled in SIPLACE Pro. On the placement machine, the com-
ponent that was not picked up is stepped forward again until it is ready for removal from the com-
ponent tape. The track is deactivated and the operator is sent an error message to remind him to
pick up the tantalum component from the tape. If an alternative track is available, the placement
machine continues placing. The operator is able to stop the placement machine, however, and re-
move the tantalum component. If no alternative track is available and it is not possible to continue
placement with other components, the machine will stop. At this point, the operator can again re-
move the tantalum component and acknowledge the error. Once the operator has restarted the
placement machine, placement is continued and components are picked up from the track that is
now enabled once more.
3
PLEASE NOTE
This software function is also a good idea for expensive components.
Please observe the safety instructions for capacitors on metallic powder basis (see section 2.4.3,
page 64
).
3 Technical data and assemblies User manual SIPLACE TX V2
3.8 SIPLACE tape feeder modules for SIPLACE TX From software version 711.1 04/2018
138
3.8.1.3 Design of the SIPLACE SmartFeeder X
The following diagram shows the design of the SIPLACE SmartFeeder X.
3
Fig. 3.8 - 1
SIPLACE SmartFeeder X
(1) Entry to the tape guide channel with tape spring
(2) Flap on cover foil container
(3) Removal handle, engaged
(4) Status display
(5) Operating panel - LED display
(6) Foil rocker
(7) Tape guide channel outlet
(8) Front slider guide
(9) Back slider guide
(1)
(2)
(3)
(4)
(5)
(6)
(8)
(9)
(7)
User manual SIPLACE TX V2 3 Technical data and assemblies
From software version 711.1 04/2018 3.8 SIPLACE tape feeder modules for SIPLACE TX
139
3.8.1.4 Design of the SIPLACE SmartFeeder Xi
3
The following diagram shows the design of the SIPLACE SmartFeeder Xi, using the example of
the SIPLACE SmartFeeder 2 x 8 mm Xi. The SIPLACE SmartFeeder Xi can be recognized by its
slanted and grooved surface on the removal handle.
3
Fig. 3.8 - 2 SIPLACE SmartFeeder 2 x 8 mm Xi
(1) Entry to the tape guide channel with tape spring
(2) Flap on cover foil container
(3) Removal handle, docked (grooved surface)
(4) Status display
(5) Operating panel - LED display
(6) Foil rocker
(7) Tape guide channel outlet
(8) Front slider guide
(9) Back slider guide
PLEASE NOTE
Maximum speed with SIPLACE SmartFeeder Xi.
The SpeedStar C&P20 P can only reach maximum speed in conjunction with the SI-
PLACE SmartFeeder Xi.
(1)
(2)
(3)
(4)
(5)
(6)
(8)
(9)
(7)
(3)
