User manual SIPLACE TX V2 6 Station extensions
From software version 711.1 04/2018 6.1 Nozzle changer
277
6.1.5 Reject bin and nozzle station
6
Fig. 6.1 - 14 Reject bin and nozzle station (example with nozzle changer for SIPLACE SpeedStar C&P20 P2)
(1) Reject bin
(2) Nozzle station
(1)
(2)
6 Station extensions User manual SIPLACE TX V2
6.1 Nozzle changer From software version 711.1 04/2018
278
6.1.5.1 Reject bin and nozzle station, TH/CPP (optional)
Item no. 03112806-xx Reject bin and nozzle station, TH/CPP
A component reject bin can be installed for the SIPLACE TwinStar and SIPLACE CPP with sta-
tionary camera. This is positioned next to the stationary camera.
6
Fig. 6.1 - 15 Reject bin and nozzle station TH/CPP
(1) Reject bin
(2) Nozzle station
(1)
(2)
User manual SIPLACE TX V2 6 Station extensions
From software version 711.1 04/2018 6.2 Reject plate
279
6.2 Reject plate
Item no. 03117664-xx Component deposit (reject plate)
If components are recognized as defective by the Vision system, these components will be placed
on the reject plate. The operator can then take these components from there.
6
Fig. 6.2 - 1 Component deposit (reject plate)
(1) Fastening screws
6.2.1 Installation position
6
Fig. 6.2 - 2 Reject plate - installation position
(1) Installation position in the placement machine
(1)
(1)
