User manual SIPLACE TX V2 2 Operational safety From software version 711.1 04/2018 2.2 Warning labels 53 2.2.9 W arning label W 205 on tape cutter 2 Fig. 2.2 - 1 1 Warning label on the top of tape cutter Item W 205, item…

100%1 / 304
2 Operational safety User manual SIPLACE TX V2
2.2 Warning labels From software version 711.1 04/2018
52
2.2.8.1 High temperatures on the SIPLACE CPP
1 in fig. 2.2 - 10
, page 51
(quantity per SIPLACE CPP: 1)
2.2.8.2 Laser mark - risk class 2 at component sensor
2
Item Laser mark - risk class 2 in fig. 2.2 - 10, page 51, item no. 03134118-01
(Quantity per CPP: 1)
0
0
0
Hight temperatures at the SIPLACE CPP during continuous opera-
tions
Risk of burns due to high temperatures!
The Z drive (linear motor) can develop high surface temperatures
during continuous operation, if the ambient temperature is greater
than 22°C.
Be careful when touching the parts.
0
LASER RADIATION
Risk class 2
Acc. to IEC 60825-1:2014
Do not look into beam!
User manual SIPLACE TX V2 2 Operational safety
From software version 711.1 04/2018 2.2 Warning labels
53
2.2.9 Warning label W 205 on tape cutter
2
Fig. 2.2 - 11 Warning label on the top of tape cutter
Item W 205, item no. 03009344-01
2
2
2
WARNING
Risk of cuts
Risk of cuts from sharp blades when working on the tape cutter!
Wear robust protective gloves when working on the tape cutter.
WARNING
Risk of injuries
Risk of injuries from pressurized compressed-air lines when working on the tape cutter.
Disconnect the placement machine from the mains supply and the compressed air
supply, before you start work on the tape cutter.
Wait until the operating pressure has dropped to 0 MPa.
W 205
2 Operational safety User manual SIPLACE TX V2
2.2 Warning labels From software version 711.1 04/2018
54
2.2.9.1 Warn label W 205 on the used tape chute
2
Fig. 2.2 - 12 Warning label on the used tape chute
Item W 205, item no. 03009344-01
(1) Warning strips
2.2.9.2 Warning label W 205
Warning labels on tape cutter and used tape chute
2
W 205 in fig. 2.2 - 11, page 53 and 2.2 - 12, page 54, item no. 03009344-01
(Quantity per placement machine: 4)
W 205
1
2
2
Risk of cuts
Risk of cuts from sharp blades when working on the tape cutter!
Observe the safety instructions in section 2.2.9, page 53).
