5 Tasks at the placement machine User manual SIPLACE TX V2 5.14 Refilling components From software version 711.1 04/2018 250 5.14 Refilling compo nent s The online help contains informa tion on refilling component s with…
User manual SIPLACE TX V2 5 Tasks at the placement machine
From software version 711.1 04/2018 5.13 Avoiding track errors
249
5.13.2 Component coordinate system and pickup angle
5
Fig. 5.13 - 1 Position of the component and its pick-up angle
Special
component
Stick
magazine:
Chip-
components
with polarity
0402
2220
The anode must be
aligned with the +X
coordinate.
Package form
type
0° coordinate system
Position in the feeder module
Pickup angle/
nozzle angle
Tape:
SOT 23
Stick
magazine:
Tape:
Tape:
SO-IC
DIL-IC
SOT 194
Tape:
Holes
Y
X
Y
X
Y
X
Y
X
Y
X
90°
90°
0°
90°
-90°
0°
5 Tasks at the placement machine User manual SIPLACE TX V2
5.14 Refilling components From software version 711.1 04/2018
250
5.14 Refilling components
The online help contains information on refilling components with and without barcodes.
With tape feeder modules, make sure that you always splice on a new tape early enough so
that the feeder modules do not run out of components.
However, do not splice the tapes too early because if you wind the tape onto the new reel
after splicing the end of the old tape, the reel with the new tape may be overfilled. The tape
could then slip off the reel and become tangled. Under certain circumstances, this could
cause pickup errors and prolonged downtime.
User manual SIPLACE TX V2 5 Tasks at the placement machine
From software version 711.1 04/2018 5.15 Docking the component trolley in or out
251
5.15 Docking the component trolley in or out
5.15.1 Safety instructions for docking component trolleys in and out
Also follow the safety instructions given in section 2.4.10, page 68.
5
5
There is a button at each location (1 and 2). The safety concept for the component trolley change-
over specifies that the operator should push this button at the relevant placement machine loca-
tion, to dock or undock the component trolley.
WARNING
DANGER OF CRUSHING!
Risk of crushing when docking and undocking the component trolley.
Always dock/undock the component trolley alone.
When docking and undocking, make sure that there are no body limbs in the travel
area of the component trolley.
PLEASE NOTE
Docking only possible if protective cover is closed
Close the protective covers.
