Before using the machine

2. Warranty

The machine you have purchased is warranted against malfunctions as described below.

Warranty Description:

Any genuine component of the machine is warranted against material or manufacturing defects and will be repaired free

of charge. (Hereafter called “warranty repair.”)

Warranty Period:

The warranty period ends after 12 months have elapsed from the time of shipment.

Items not covered by the warranty: The warranty does not cover any of the following conditions:

1. Damage resulting from deterioration due to age or wear (e.g., normal discoloration of painted or plated surfaces, wear

of expendable parts, etc.)

2. Damage resulting from the user environment (e.g., impurities in the air supply, dust, debris, oil mist, etc., on the

machine.)

Warranty repairs do not cover damage caused by the following:

1. Earthquake, typhoon, floods, lightening, accidents or fires and other natural or man-made disasters

2. Modifications or conversions not approved by Yamaha or its distributors

3. Use of non-genuine components, greases and lubricants

4. Lack and errors in proper maintenance and inspection procedures

5. Maintenance handled by anyone other than approved distributors

iii

Before using the machine

3. Handling Precautions

To maintain the performance characteristics of the machine you purchased, note the following point when

using the parts feeders.

Air-blow positions when exchanging parts (tape reel)

Be sure to blow air to the following positions before exchanging parts.

• Sprocket assembly part (Figure 1 below)

Blow air to the entire part.

• Empty tape feed groove (Figure 2 below)

Blow air in the directions of the arrows.

• Inside top tape box of the top tape winding gear (Figure 3 below)

Blow air in the direction of the arrow.

Air-blow positions when exchanging parts

63001-9L-10

CAUTION

If a tape-and-reel packing is set with a component still remained in the tape guide assembly, etc., the carrier tape or

the top tape will be caught in the feeder, causing component feeding errors. Take care or pickup error may be caused.

NOTE

Recommended Air Blow Tool : KU4-M8590-00X AIR BLOW TOOL

Before using the machine

Precautions for setting the feeder

· Before setting the feeder, be sure to remove foreign matter (part, etc.) on the feeder plate upper surface.

CAUTION

· If the tape feeder is set with foreign matter on the feeder plate, lower surface of the feeder will be damaged. Take

care or malfunction of the feeder such as pickup error may be caused.

· Use a dustpan or the like when cleaning the upper feeder plate so that wiped foreign matter would not fall on the

lower section.

· Take care not to let wiped foreign matter be caught in the connector part when cleaning the lower feeder plate.

Removing foreign matter on the upper feeder plate

63003-F3-00

Removing foreign matter on the lower feeder plate

Connector part

63004-F3-00

· Be sure to clean the upper surface of the feeder plate before setting the feeder.
